神钢零件查询(6D16-T) - MITSUBISHI DIESEL ENGINE - K909LC & MD240BLC (1/87-12/06) (02-018) - OIL LINE (PN VAME034545) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
272 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-4. | VAME034545 | [1] | INTAKE VALVE GUIDE | KOBREGULATING Superseded by part number: VAME074455 |
| 1. | VAME034546 | [1] | VALVE BODY | VALVE BODY |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONVALVE, RELIEF |
| 3. | VAME034548 | [1] | SPRING | KOBRELIEF/V |
| 4. | VAMF522207 | [1] | RING | KOBRING, SNAP 16 |
| 5. | VAMF660071 | [1] | PACKING | KOBGASKET 27 |
| 6. | VAMH035129 | [1] | O-RING | KOBO-RING |
| 7. | VAME074015 | [1] | PIPE | KOBFOR I/P, A/COMPR |
| 9. | VA3007554900 | [2] | CLAMP | KOBCLAMP |
| 10. | VAMH022205 | [2] | PROTECTOR | KOBPROTECTOR |
| 11. | VAMF241227 | [2] | BOLT | KOBB0LT, W/WSR, 6 X 20 |
| 12. | VAMH000119 | [1] | BOLT | KOBBOLT, JOINT |
| 13. | VAMF660063 | [6] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 14. | VAME034051 | [1] | HYD CONNECTOR | KOB |
| 15. | VAME074017 | [1] | STAY | |
| 16A. | VAMS666222 | [1] | PLUG | SMPLUG, TAPER, PT3/8 |
| 17. | VAME031088 | [1] | PLUG | KOB |
| . . | VAMF660063 | [1] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 45. | VAME070571 | [1] | INJECTION PIPE | KOB |
| 46. | VAMF650102 | [1] | SCREW | KOBBOLT, JOINT |
| 47. | VAME930095 | [2] | STAY | KOB |
| 48. | VA3004901300 | [2] | CLAMP | KOB |
| 49. | VAMH000399 | [2] | SCREW | KOBBOLT, 8 X 16 |
| 50. | VAMF140005 | [2] | BOLT | KOBBOLT, FLANGE, 8 X 16 |
| 51. | VAME070572 | [1] | INJECTION PIPE | KOB |
| 52. | VAME070510 | [1] | GASKET | KOB Superseded by part number: VAME078273 |
| 52A. | VAME014559 | [1] | GASKET | KOB Superseded by part number: VAME073842 |
| 53. | VAMH000931 | [2] | BOLT | KOBBOLT, FLANGE, 10 x 18 Superseded by part number: 132361A1 |
| 54. | VAMF241224 | [2] | BOLT | KOBBOLT, W/WSR, 6 X 14 |
| 55. | VAME030900 | [1] | COVER, SIDE RE | COVER, SIDE RE |
| 56. | VAME031155 | [1] | GASKET | KOBSIDE COVER Superseded by part number: 77269054, VAME071274 |
| 57. | VAMF140221 | [8] | BOLT | KOBBOLT, FLANGE, 8 X 12 |
