凯斯零件查询(RB454) - CASE IH ROUND BALER (7/07-1/14) (15.14[1]) - TWINE ARM DRIVE BRACKET, P.I.N. Y9N043084 & PRIOR Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
506 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
25121
|
[1] |
SNAP RING,#100, Ext
|
NH
|
| 2. |
86643718
|
[1] |
ARM
|
NH
|
| 3. |
86629116
|
[1] |
BRACKET
|
NH
Superseded by part number: 87652999
|
| 4. |
602505
|
[1] |
BALL
|
NH
|
| 5. |
86636632
|
[1] |
SPRING
|
NH
|
| 6. |
603153
|
[1] |
PLUG
|
NH
|
| 7. |
86636725
|
[1] |
REDUCER,3/8" - 16
|
NH
|
| 8. |
87020316
|
[1] |
SET SCREW,Hex Skt, 3/8" - 16 x 1 1/2"
|
GI
|
| 9. |
280436
|
[1] |
CARRIAGE BOLT,Short Sq Nk, 1/2" - 13 x 2 1/4", Gr 5
|
NH
|
| 12. |
87414
|
[1] |
LUBE NIPPLE,1/4" - 28
|
NH
|
| 14. |
26129
|
[4] |
WASHER,25.8mm ID x 39.69mm OD x 0.99mm Thk
|
NH
(1-1/64" ID x 1-9/16" OD x 0.036")
|
| 17. |
86509499
|
[1] |
JAM NUT,3/8"-16, G2
|
ZED
|
| 20. |
219-87
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
