现代零件查询R170W-7 QUICK CLAMP HYD PIPING(#0092-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
325 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
QUICK CLAMP PIPING
|
|
| 1. |
@
|
[1] |
QUICK CLAMP ASSY
|
|
| 2. |
34EA-91720
|
[1] |
SOLENOID VALVE
|
|
| 2-1. |
34EA-91720B
|
[1] |
MANIFOLD
|
|
| 2-2. |
GS044200NC
|
[1] |
VALVE-SOLENOID
|
|
| 2-3. |
CAP024L-DT
|
[1] |
COIL
|
|
| 3. |
31N4-90680
|
[1] |
TERMINAL-Q/CLAMP
|
|
| 3. |
31N4-90680
|
[2] |
TERMINAL-Q/CLAMP
|
|
| 3-1. |
X540-120001
|
[2] |
CONNECTOR-ORFS
|
|
| 3-2. |
S621-011001
|
[6] |
O-RING
|
|
| 4. |
P913-047034
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 4. |
P913-047028
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 4. |
P913-047037
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 5. |
31N5-90530
|
[1] |
PIPE ASSY
|
|
| 5. |
31N5-90540
|
[1] |
PIPE ASSY
|
|
| 6. |
31N5-90550
|
[1] |
PIPE ASSY
|
|
| 6. |
31N5-90560
|
[1] |
PIPE ASSY
|
|
| 7. |
P920-047144
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 7. |
P910-047091
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 7. |
P920-047150
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 7. |
P910-047097
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 8. |
P910-047030
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 8. |
31N4-95750
|
[1] |
HOSE ASSY
|
|
| 9. |
P930-042009
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 10. |
S017-160752
|
[1] |
BOLT-HEX
|
|
| 10. |
S017-160752
|
[2] |
BOLT-HEX
|
|
| 11. |
S411-160002
|
[1] |
WASHER-SPRING
|
|
| 11. |
S411-160002
|
[2] |
WASHER-SPRING
|
|
| 12. |
34EA-91811
|
[3] |
CLAMP-PIPE
|
|
| 13. |
S017-100302
|
[3] |
BOLT-HEX
|
|
| 14. |
31N4-22170
|
[1] |
TEE-RUN TYPE
|
|
| 15. |
X500-110001
|
[2] |
CONNECTOR-ORFS
|
|
| 16. |
S631-011004
|
[5] |
O-RING
|
|
| 17. |
X520-110001
|
[2] |
ELBOW-90,ORFS
|
|
| 18. |
S441-100002
|
[5] |
WASHER-HARDENED
|
|
| 19. |
S017-100502
|
[2] |
BOLT-HEX
|
|
| 20. |
S554-054300
|
[25] |
CLAMP-BAND
|
|
| 21. |
S621-011001
|
[14] |
O-RING
|
|
| 21. |
S621-011001
|
[18] |
O-RING
|
|
| 22. |
P920-047049
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
