纽荷兰零件查询(CV2500) - VIBRATORY ROLLER (12-012-00[01]) - VIBRATORY - DRUM New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
290 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND011893 | [2] | ECCENTRIC | STA |
| 2. | ND011895 | [2] | ECCENTRIC | STA |
| 3. | ND017267 | [1] | SHAFT | STA |
| 4. | ND017269 | [1] | SHAFT | STA |
| 5. | ND104694 | [1] | SHAFT | STA |
| 6. | ND029020 | [1] | BREAKER POINTS | STA |
| 7. | ND028192 | [2] | RING | STA |
| 8. | ND028233 | [2] | RING | STA |
| 11. | ND033854 | [2] | KEY | STA |
| 12. | ND048385 | [2] | PIN | STA6 x 32 |
| 14. | ND068952 | [4] | BEARING | STA |
| 15. | ND069918 | [2] | CIRCLIP | STA |
| 16. | ND069838 | [4] | SNAP RING | STA |
