现代零件查询R170W-7 SINGLE ACTING MAIN PIPING KITEPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
424 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
S/ACT HYD PIPING KIT
|
|
| -1. |
@
|
[1] |
S/ACT PIPING KIT
|
|
| -11. |
@
|
[1] |
S/ACT MAIN PIPING KIT
|
|
| 1. |
31N5-94710
|
[2] |
BLOCK-HOSE JOINT
|
|
| 2. |
31N6-91230D
|
[1] |
SOLENOID VLV-BREAKER
|
|
| 2-1. |
XKBN-00192
|
[1] |
COIL-BREAKER SOL
|
|
| 3. |
31N6-93230
|
[1] |
BRACKET-SOL VLV
|
|
| 4. |
P973-166325
|
[2] |
HOSE ASSY-ORFSXFLG
|
|
| 5. |
P933-126016
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 6. |
P923-163020
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 7. |
P910-042052
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 8. |
P930-042018
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 9. |
P930-042046
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 10. |
X500-110001
|
[1] |
CONNECTOR-ORFS
|
|
| 11. |
X511-112546
|
[1] |
CONNECTOR-ORFS
|
|
| 12. |
X500-110005
|
[1] |
CONNECTOR-ORFS
|
|
| 13. |
X511-116556
|
[2] |
CONNECTOR-ORFS
|
|
| 14. |
X530-110018
|
[1] |
ELBOW-45,ORFS
|
|
| 15. |
X520-110001
|
[3] |
ELBOW-90,ORFS
|
|
| 16. |
X820-045151
|
[1] |
TEE-R/TYPE,ORFS
|
|
| 17. |
S631-011004
|
[5] |
O-RING
|
|
| 18. |
S631-024004
|
[1] |
O-RING
|
|
| 19. |
S631-029004
|
[4] |
O-RING
|
|
| 20. |
S621-011001
|
[7] |
O-RING
|
|
| 21. |
S621-018001
|
[2] |
O-RING
|
|
| 22. |
S621-021001
|
[4] |
O-RING
|
|
| 23. |
S109-080456
|
[2] |
BOLT-SOCKET
|
|
| 24. |
S109-120556
|
[4] |
BOLT-SOCKET
|
|
| 25. |
S017-100256
|
[2] |
BOLT-HEX
|
|
| 26. |
S411-080006
|
[2] |
WASHER-SPRING
|
|
| 27. |
S411-100006
|
[2] |
WASHER-SPRING
|
|
| -12. |
@
|
[1] |
ATTACH PIPING KIT
|
|
| 46. |
31N4-90530
|
[1] |
PORT RELIEF VALVE
|
|
| 48. |
21E6-30540
|
[1] |
SWITCH-BREAKER
|
|
