纽荷兰零件查询(CV2500) - VIBRATORY ROLLER (12-022-00[01]) - OPERATORS COMPARTMENT New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
612 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND106158 | [1] | PLATFORM | STA |
| 2. | ND029730 | [1] | COVER | STA |
| 3. | ND106210 | [2] | HOLDER | STA |
| 4. | ND053517 | [1] | FLEXIBLE HOSE | STA Superseded by part number: ND108074 |
| 5. | ND050477 | [1] | PADDING | STA |
| 8. | ND106246 | [4] | RING | STA |
| 9. | ND050824 | [1] | LINK CHAIN | STA |
| 10. | ND031878 | [1] | DRIVER SEAT | STA |
| 13. | ND105740 | [1] | PEDESTAL | STA |
| 14. | ND090877 | [1] | HOLDER | STA |
| 15. | ND069396 | [1] | FIRE EXTINGUISHER | STA |
| 16. | ND064408 | [2] | MIRROR | STA |
| 18. | ND064664 | [2] | CLAMP | STA |
| 19. | ND101585 | [1] | PLASTIC-RUBBER TUBE | STA |
| 24. | ND024248 | [4] | BOLT | STA |
| 25. | ND021295 | [8] | BOLT | STA |
| 26. | ND021293 | [2] | BOLT | STA |
| 27. | ND021286 | [2] | BOLT | STA |
| 28. | ND024124 | [2] | BOLT | STA |
| 29. | ND024121 | [2] | BOLT | STA |
| 30. | ND024388 | [4] | SCREW | STA |
| 34. | ND021848 | [13] | NUT | STA Superseded by part number: ND034087 |
| 35. | ND021847 | [2] | NUT | STA |
| 36. | ND027301 | [4] | NUT | STA |
| 39. | ND029266 | [8] | WASHER | STA |
| 40. | ND029249 | [8] | WASHER | STA |
| 41. | ND029247 | [2] | WASHER | STA |
| 43. | ND035940 | [12] | SPRING WASHER | STA |
| 44. | ND029309 | [2] | SPRING WASHER | STA |
