纽荷兰零件查询(CV2500) - VIBRATORY ROLLER (12-028-00[01]) - DECALS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
185 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 72195730 | [1] | ADHESIVE | STA Superseded by part number: ND106427 |
| 2. | 72191644 | [2] | DECAL | STA Superseded by part number: ND104580 |
| 3. | ND104444 | [1] | DECAL | STA |
| 4. | ND081871 | [1] | DECAL | STA |
| 5. | ND081629 | [1] | DECAL | STA |
| 6. | ND081458 | [1] | DECAL | STA |
| 7. | ND081677 | [1] | DECAL | STA |
| 8. | ND081517 | [2] | DECAL | STA |
| 9. | ND081465 | [1] | DECAL | STA |
| 10. | ND081770 | [1] | DECAL | STA |
| 11. | ND081590 | [1] | DECAL | STA |
| 12. | ND081612 | [1] | DECAL | STA |
| 13. | ND081828 | [1] | DECAL | STA |
| 14. | ND081768 | [1] | DECAL | STA |
| 15. | ND081766 | [1] | DECAL | STA |
| 16. | ND101121 | [1] | ADHESIVE | STA |
| 17. | ND081459 | [1] | DECAL | STA |
| 18. | ND081611 | [1] | DECAL | STA |
| 19. | ND081460 | [4] | DECAL | STA |
| 20. | ND081722 | [1] | ADHESIVE | STA |
| 21. | ND104862 | [2] | DECAL | STA |
| 22. | ND081887 | [1] | DECAL | STA |
| 23. | ND081852 | [1] | DECAL | STA |
| 24. | ND081886 | [1] | DECAL | STA |
| 25. | ND104587 | [1] | ADHESIVE | STA |
| 26. | ND081593 | [1] | DECAL | STA |
| 27. | ND081530 | [1] | DECAL | STA |
| 28. | ND081822 | [1] | DECAL | STA |
| 29. | ND081592 | [1] | DECAL | STA |
