神钢零件查询(6D22) - MITSUBISHI DIESEL ENGINE - K909A, K912A, K916, & K935 (1/76-12/06) (01-008) - CONNECTING ROD & BEARING Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
345 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D22TC ALL | [1] | CONNECTING ROD & ASSEMBLY, M0 | |
| . . | 6D22T ALL | [1] | CONNECTING ROD & ASSEMBLY, M0 | |
| . . | 6D22Z ALL | [1] | CONNECTING ROD & ASSEMBLY, M0 | |
| 1-5. | VAME052330 | [6] | CONN. ROD SHELL | KOBCONNECTING ROD ASSY Superseded by part number: VAME052825 |
| 1. | NSS | [6] | NOT SOLD SEPARAT | CONROD, CONNECTING |
| 2. | NSS | [6] | NOT SOLD SEPARAT | CONCAP, CONNECTING |
| 3. | VA3091900400 | [24] | BOLT | KOBBOLT, REAMER |
| 4. | VAME032042 | [24] | NUT | KOB Superseded by part number: 132467A1 |
| 5. | VAME052660 | [6] | BUSHING | KOB Superseded by part number: 132465A1 |
| 6. | VAME052488 | [1] | BEARING SET | KOBCONN-ROD, ONE MODEL, STD Superseded by part number: 132480A1 |
| . . | VAME052489 | [1] | BEARING,CON.ROD | KOBBEARING, CON. ROD US, 0.25 Superseded by part number: 132481A1 |
| . . | VAME052490 | [1] | BEARING SET | KOBUS, 0.50 Superseded by part number: 132482A1 |
| . . | VAME052491 | [1] | SET | KOBUS, 0.75 |
| . . | VAME052492 | [1] | SET OF STD MAIN BRGS | KOBUS, 1.00 Superseded by part number: 132484A1 |
