纽荷兰零件查询(CV700) - VIBRATORY ROLLER (9/01-) (04-002-00[01]) - INSTRUMENT PANEL New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
527 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND103337 | [1] | PLATE | STA |
| 3. | ND103332 | [1] | SUPPORT | STA |
| 4. | ND054391 | [1] | SUPPORT | STA |
| 9. | ND104426 | [1] | GAUGE | STA |
| 10. | ND098757 | [1] | THERMOMETER | STA Superseded by part number: ND104425 |
| 11. | ND098758 | [1] | FUEL GAUGE | STA |
| 12. | ND098759 | [1] | HOURMETER | STA Superseded by part number: ND136619 |
| 14. | ND064513 | [1] | IGNITION SWITCH | STAIncludes 73171248 Key |
| 15. | ND064514 | [1] | COVER | STA |
| 16. | ND064523 | [1] | LAMP SOCKET | STA |
| 19. | ND065309 | [6] | BEZEL | STA |
| 20. | ND065310 | [8] | TERMINAL | STA |
| 21. | ND065398 | [4] | INDICATOR LIGHT | STA |
| 22. | ND065391 | [7] | COVER | STA |
| 23. | ND065315 | [1] | SWITCH | STAPark Brake |
| 24. | ND065396 | [1] | SWITCH | STA |
| 27. | ND065353 | [1] | LENS | STA |
| 28. | ND065354 | [1] | LENS | STA |
| 29. | ND065346 | [1] | LENS | STA |
| 30. | ND065418 | [1] | TAG | STA |
| 31. | ND065349 | [1] | LENS | STA |
| 32. | ND065423 | [1] | DECAL | STA |
| 33. | ND065390 | [1] | LENS | STA |
| 34. | ND065359 | [1] | LENS | STA |
| 35. | ND065403 | [1] | LENS | STA |
| 36. | ND065413 | [1] | LENS | STA |
| 37. | ND065422 | [8] | LAMP REFLECTOR | STA |
| 40. | ND081546 | [1] | TAG | STA |
| 41. | ND081796 | [1] | DECAL | STA |
| 42. | ND081821 | [1] | DECAL | STA |
| 45. | ND064517 | [1] | FUSE BOX | STA |
| 46. | ND064515 | [4] | ELEC CONNECTOR | STA |
| 47. | ND065918 | [1] | FUSE | STA7,5 Amp Superseded by part number: 87522595 |
| 48. | ND065922 | [2] | FUSE | STA10 Amp Superseded by part number: 87522597 |
| 49. | ND065919 | [1] | FUSE | STA15 Amp Superseded by part number: 87524877 |
| 50. | ND065923 | [2] | FUSE | STA20 Amp Superseded by part number: 10401190 |
| 52. | ND065142 | [6] | RELAY | STA24V |
| 53. | ND065143 | [6] | HOLDER | STA |
| 54. | ND066654 | [1] | RESISTOR | STA |
| 55. | ND066655 | [1] | RESISTOR | STA |
| 56. | ND066634 | [2] | DIODE | STA |
| 57. | ND079697 | [4] | RING | STA |
| 58. | ND098737 | [1] | RELAY | STA |
| 61. | ND024109 | [2] | BOLT | STAM4 x 10 |
| 62. | ND093424 | [6] | BOLT | STAM5 x 10 |
| 63. | ND021285 | [6] | BOLT | STAM5 x 12 |
| 64. | ND021172 | [2] | BOLT | STAM5 x 80 |
| 67. | ND021846 | [11] | NUT | STAM5 |
| 70. | ND029325 | [2] | WASHER | STAID 4,3 |
| 71. | ND029308 | [14] | WASHER | STAID 5,1 |
| 73. | ND029246 | [2] | WASHER | STAID 4,3 |
| 74. | ND029247 | [1] | WASHER | STAID 5,3 |
