神钢零件查询(6D22) - MITSUBISHI DIESEL ENGINE - K909A, K912A, K916, & K935 (1/76-12/06) (01-018[01]) - TURBO-CHARGER GENERAL Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
317 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D221CT-KS03 | [1] | TURBOCHARGER GENERAL(M3) | |
| . . | 60221CT-KS09 | [1] | TURBOCHARGER GENERAL(M1) | |
| . . | 6D221CT-KS04 | [1] | TURBOCHARGER GENERAL(M1) | |
| . . | 6D221CT-KS01 | [1] | TURBOCHARGER GENERAL(M1) | |
| 1. | VAME058448 | [1] | TURBOCHARGER | KOBTURBOCHARGER ASSY 3LM319 |
| 4. | VA3003291200 | [1] | GASKET | KOBGASKET Superseded by part number: VAME150877 |
| 6. | VAMH004110 | [8] | NUT | KOBNUT 10 (FOR M1) Superseded by part number: 134957A1 |
| . . | VAMH004110 | [8] | NUT | KOBNSS (FOR M3) Superseded by part number: 134957A1 |
| 7. | VAME058625 | [1] | PIPE | KOBPIPE,INLET |
| 7A. | VAME031087 | [1] | SET OF SCREWS | KOBPLUG |
| . . | VAMF660063 | [1] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 9. | VAMH000245 | [4] | BOLT | KOBBOLT,W/WSR 10X58 |
| 10. | VA3014000900 | [4] | BOLT BOLT 10X125 | BOLT BOLT 10X125 |
| . . | VAMF450406 | [4] | WASHER | KOBWASHER,SPG 10 |
| . . | VAMF450006 | [4] | NUT | KOBWASHER,PLAIN 10 Superseded by part number: 133247A1 |
| 11. | VAME053453 | [1] | HOSE | KOBHOSE,RUBBER |
| 12. | VAMH021321 | [2] | CLAMP | KOBCLAMP,HOSE Superseded by part number: 134981A1 |
| 15. | VAME058466 | [1] | COUPLER,INLET (FOR M1) | |
| . . | VAME058681 | [1] | COUPLER,INLET NSS (FOR M3) | COUPLER,INLET NSS (FOR M3) |
| 16. | VA3003096800 | [1] | HOSE, BULK | KOBHOSE, METERS HOSE,RUBBER |
| 17. | VA3123011830 | [1] | CLAMP | KOBHOSE Superseded by part number: 134980A1 |
| 18. | VA3123011840 | [1] | CLAMP | KOBHOSE Superseded by part number: 134979A1 |
| 20. | VA3003291300 | [1] | HINGE | KOBJOINT,TURBINE |
| 21. | VAME063946 | [2] | SEAL RETAINER | KOBRING,SEAL Superseded by part number: 134995A1 |
| 27. | VAMH005027 | [2] | WASHER | KOBWASHER |
| 50. | VAME058926 | [1] | PIPE | KOBPIPE,OIL INLET |
| 53. | VA3093690900 | [2] | CLAMP | KOBCLAMP |
| 54. | VA3127516500 | [1] | SPACER | KOBSPACER L=20 |
| 55. | VAME920004 | [1] | SPACER | KOBSPACER L=5 |
| 56. | VAMH022152 | [2] | OIL SEAL | KOBPROTECTOR,RUBBER |
| 60. | VAMH037254 | [1] | BOLT | KOBBOLT,EYE |
| 64. | VAME058999 | [1] | PIPE , A OIL OUTLET PIPE,A OIL OUTLET (FOR M1) | PIPE , A OIL OUTLET PIPE,A OIL OUTLET (FOR M1) |
| . . | VAME058999 | [1] | PIPE , A OIL OUTLET NSS (FOR M3) | PIPE , A OIL OUTLET NSS (FOR M3) |
| 67. | VAMF300841 | [1] | SCREW | KOBBOLT,W/WSR 10X20 (FOR M1) Superseded by part number: 132461A1 |
| . . | VAMF300841 | [1] | SCREW | KOBNSS (FOR M3) Superseded by part number: 132461A1 |
| 68. | VA3123612600 | [1] | GASKET | KOBGASKET Superseded by part number: 133176A1 |
| 69. | VAMH000886 | [2] | BOLT BOLT 3/8-16UNC | BOLT BOLT 3/8-16UNC |
| 70. | VAME054279 | [1] | HOSE | KOBHOSE,RUBBER |
| 71. | VAMF661017 | [2] | CLAMP CLAMP,HOSE 33 | CLAMP CLAMP,HOSE 33 |
| 72. | VAME058819 | [1] | PIPE | KOBPIPE,B OIL |
| 73. | VA3094291400 | [1] | GASKET | KOBGASKET |
| 74. | VAMF300841 | [2] | SCREW | KOBBOLT,W/WSR 10X20 Superseded by part number: 132461A1 |
| 75. | VAMH005027 | [2] | WASHER | KOBSPACER T=3.2 |
