凯斯零件查询(RB454) - CASE IH ROUND BALER (7/07-1/14) (18.82) - DIA KIT, DUMMY KNIFE HOLDER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
319 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47371570
|
[1] |
DIA KIT, HARVESTER
|
NH
Dummy Knife Holder, Incl 2 - 9
|
| 2. |
47812490
|
[1] |
INSTRUCTION
|
PLO
|
| 3. |
86616730
|
[1] |
HOLDER
|
NH
|
| 4. |
87036001
|
[15] |
KNIFE
|
PA
Dummy Section
|
| 5. |
9804261
|
[2] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 6. |
86511448
|
[2] |
COTTER PIN,0.148" Dia x 3.31" L
|
NH
Superseded by part number: 80033778
|
| 7. |
NH291525
|
[1] |
EDGE
|
NH
Superseded by part number: 86516805
|
| 8. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 9. |
9804278
|
[2] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
