纽荷兰零件查询(CV700) - VIBRATORY ROLLER (9/01-) (10-002-00[01]) - HYDRAULIC CIRCUIT - VIBRATION New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
340 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4. | ND062140 | [1] | HYD CONNECTOR | STA |
| 5. | ND062181 | [1] | HYD CONNECTOR | STA |
| 6. | ND062135 | [3] | HYD CONNECTOR | STA |
| 8. | ND062129 | [2] | HYD CONNECTOR | STA |
| 9. | ND101487 | [2] | HYD CONNECTOR | STA |
| 10. | ND062427 | [2] | HYD CONNECTOR | STA |
| 12. | ND062450 | [2] | HYD CONNECTOR | STA |
| 13. | ND062420 | [1] | PLUG | STA |
| 15. | ND102238 | [1] | HOSE,3300.00 mm | STA |
| 17. | ND102233 | [1] | HOSE,550.00 mm | STA |
| 18. | ND102234 | [1] | FLEXIBLE HOSE | STA540mm Superseded by part number: ND108310 |
| 20. | ND102229 | [1] | HOSE,2600.00 mm | STA |
| 21. | ND102228 | [1] | HOSE,2650.00 mm | STA |
| 25. | ND106910 | [10] | STRAP | STA |
