久保田零件查询F20500 DIFFERENTIAL LOCK PEDAL REAR AXLEEPC Kubota online
广数供应链运营团队, 14 02月, 2025，浏览：
720 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
3272119120
|
[1] |
ROD FORK
|
0.3740(lbs); 0.170
|
| 020. |
0481106120
|
[1] |
O RING
|
0.0022(lbs); 0.001
|
| 020. |
0481606120
|
[1] |
O RING
|
0.0044(lbs); 0.002
|
| 030. |
0501201025
|
[1] |
PIN STRAIGHT
|
0.0352(lbs); 0.016
|
| 030. |
6A10019130
|
[1] |
PIN
|
0.0374(lbs); 0.017
|
| 040. |
6C04019110
|
[1] |
FORK DIFF.LOCK SHIFT
|
0.4840(lbs); 0.220
|
| 050. |
6C04019130
|
[1] |
SPRING
|
0.0308(lbs); 0.014
|
| 060. |
6661115130
|
[1] |
CLUTCH DIFF.LOCK
|
0.4400(lbs); 0.200
|
| 070. |
6C05042872
|
[1] |
PEDAL DIFF.LOCK
|
2.6400(lbs); 1.200
|
| 080. |
3741042760
|
[1] |
COVER PEDAL
|
0.0550(lbs); 0.025
|
| 090. |
6C05042890
|
[1] |
SPRING
|
0.0880(lbs); 0.040
|
| 100. |
6C04042880
|
[1] |
ROD DIFF.LOCK
|
0.2200(lbs); 0.100
|
| 110. |
0551150215
|
[1] |
PIN SPLIT
|
0.0022(lbs); 0.001
|
| 120. |
0552550800
|
[1] |
PIN SNAP
|
0.0022(lbs); 0.001
|
