神钢零件查询(6D22) - MITSUBISHI DIESEL ENGINE - K909A, K912A, K916, & K935 (1/76-12/06) (03-007) - FUEL FEED PUMP (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
303 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D221CT-KS0B | [1] | FUEL FEED PUMPS(INNER PARTS)(M3) | |
| . . | 6D221C1-KS01 | [1] | FUEL FEED PUMPS(INNER PARTS)(M3) | |
| . . | 6D221CT-KS09 | [1] | FUEL FEED PUMPS(INNER PARTS)(M0) | |
| . . | 6D221CT-KS04 | [1] | FUEL FEED PUMPS(INNER PARTS)(M0) | |
| . . | 6D221CZ-KS0A | [1] | FUEL FEED PUMPS(INNER PARTS)(M0) | |
| . . | 6D221CZ-KS06 | [1] | FUEL FEED PUMPS(INNER PARTS)(M0) | |
| . . | 6D221CZ-KS09 | [1] | FUEL FEED PUMPS(INNER PARTS)(M0) | |
| . . | 6D221CZ-KS07 | [1] | FUEL FEED PUMPS(INNER PARTS)(M0) | |
| . . | 6D221CT-KS03 | [1] | FUEL FEED PUMPS(INNER PARTS)(M0) | |
| . . | 6D221CZ-KS04 | [1] | | |
| 1-36. | VAME056098 | [1] | ENGINE OIL PUMP | KOBFUEL FEED PUMP ASSY KE TYPE(FOR M0 ONLY) |
| 1-42. | VAME059636 | [1] | PUMP | KOBFUEL FEED PUMP ASSY TYPE(FOR M3 ONLY) Superseded by part number: 133424A1 |
| 1. | 52004092 | [1] | HOUSING,PUMP(FOR M0 ONLY) | |
| . . | 52000462 | [1] | (FOR M3 ONLY) | |
| 5. | 52100112 | [1] | PISTON | |
| 6. | 52102040 | [1] | SPRING,PISTON | |
| 7. | 52105020 | [1] | PLUG | |
| 8. | 29332603 | [1] | GASKET | |
| 10. | 52111292 | [1] | TAPPET ASSY (FOR MO ONLY) | |
| . . | 52111322 | [1] | (FOR M3 ONLY) | |
| 14. | 52115020 | [2] | VALVE | |
| 15. | 52116020 | [2] | SPRING | |
| 16. | 52117010 | [1] | PLUG(FOR MO ONLY) | |
| . . | 52117040 | [1] | (FOR M3 ONLY) | |
| 18. | 29331603 | [2] | GASKET | |
| 20. | 52121020 | [1] | RING,SNAP | |
| 25. | 52200112 | [1] | PRIMING PUMP (FOR MO ONLY) | |
| . . | 52200212 | [1] | (FOR M3 ONLY) | |
| 30. | 52300712 | [1] | BOLT,EYE | |
| 32. | 29731457 | [1] | BOLT,EYE | |
| 35. | 29341413 | [2] | GASKET | |
| 36. | 29341413 | [2] | GASKET | |
| 42. | 52320010 | [1] | COVER(FOR M3 ONLY) | |
