凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (31.220.AL[02]) - VAR - 726872 - GEARBOX AND DRIVE, STANDARD, 1000 RPM, YFN188618 AND PRIOR Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
842 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84526344
|
[1] |
MOUNT
|
PLO
1000 RPM
|
| 2. |
84526345
|
[1] |
MOUNTING PLATE
|
PLO
1000 nM, Slip Clutch
|
| 3. |
87344585
|
[1] |
GEARBOX
|
PA
1000 RPM, Standard Duty
|
| 3. |
87344585R
|
[1] |
REMAN-PTO GEARBOX A.
|
PA
1000 RPM, Standard Duty
|
| 3. |
87344585C
|
[1] |
CORE-PTO GEARBOX A.
|
PA
Return Number
|
| 4. |
86626271
|
[1] |
DIPSTICK
|
NH
|
| 5. |
47372356
|
[1] |
PTO
|
NH
COC, 1100 N-M
|
| 6. |
86634418
|
[1] |
COUPLING
|
NH
Incl 7, 13 - 15 Superseded by part number: 87661924
|
| 7. |
86637396
|
[2] |
WASHER,25.6mm ID x 35.3mm OD x 1mm Thk
|
NH
|
| 8. |
87664061
|
[1] |
DRIVE SHAFT
|
NH
|
| 9. |
86979179
|
[4] |
WASHER,16.67mm ID x 34.93mm OD x 6.35mm Thk
|
NH
|
| 10. |
9804272
|
[4] |
BOLT,Hex, M16 x 50mm, Cl 8.8, Full Thd
|
NH
|
| 11. |
9804271
|
[4] |
BOLT,Hex, M16 x 40mm, Cl 8.8, Full Thd
|
NH
|
| 12. |
9804280
|
[4] |
FLANGE NUT,Hex, M16, Cl 8
|
NH
Superseded by part number: 86512498
|
| 13. |
300643
|
[2] |
SNAP RING,M38, Int
|
NH
Superseded by part number: 11059776
|
| 14. |
62161
|
[2] |
LUBE NIPPLE,M8 x 1.25, Str
|
NH
|
| 15. |
86637370
|
[2] |
SEAL,40mm ID x 52mm OD x 7mm Thk
|
NH
|
