凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (31.220.AL[05]) - VAR - 726527 - GEARBOX AND DRIVE, 540 RPM, YFN188619 AND AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
795 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87391830
|
[1] |
GEARBOX
|
PA
540 RPM
|
| 2. |
84253264
|
[1] |
PTO
|
PLO
Slip Clutch, 1700 Nm
|
| 3. |
86634418
|
[1] |
COUPLING
|
NH
Incl 8 Superseded by part number: 87661924
|
| 4. |
47623676
|
[1] |
SHAFT
|
PLO
|
| 5. |
86626270
|
[1] |
DIPSTICK,129mm L
|
NH
|
| 6. |
86979179
|
[4] |
WASHER,16.67mm ID x 34.93mm OD x 6.35mm Thk
|
NH
|
| 7. |
9804271
|
[4] |
BOLT,Hex, M16 x 40mm, Cl 8.8, Full Thd
|
NH
|
| 8. |
86637396
|
[2] |
WASHER,25.6mm ID x 35.3mm OD x 1mm Thk
|
NH
|
