神钢零件查询(6D22) - MITSUBISHI DIESEL ENGINE - K912, K912LC, & K916 (1/83-12/06) (01-010) - FLY WHEEL 020-290A Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
620 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-3. | VAME052658 | [1] | FLYWHEEL ASSY M0 ONLY | FLYWHEEL ASSY M0 ONLY |
| 1-2. | VAME058037 | [1] | FLYWHEEL ASSY, M1 ONLY | |
| . . | VAME058036 | [1] | M2 ONLY | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONFLYWHEEL |
| 2. | VAME062828 | [1] | RING GEAR | KOBZ=143 Superseded by part number: 132458A1 |
| 3. | VAMF472405 | [2] | DOWEL | KOBPIN, DOWEL 10 Superseded by part number: 132323A1 |
| 4. | VAMH040026 | [1] | BALL BEARING | KOBBEARING, BALL Superseded by part number: 134774A1 |
| 5. | VAMF522236 | [1] | SNAP RING | KOBRING, SNAP 62 |
| 6. | VAME052691 | [8] | BOLT | KOB |
