| 1. |
47623827
|
[1] |
TAILGATE
|
NH
Incl 29 - 30
|
| 2. |
47540586
|
[2] |
LATCH
|
NH
Tailgate
|
| 3. |
47853346
|
[1] |
HOOK
|
PLO
RH
|
| 4. |
47853260
|
[1] |
HOOK
|
NH
LH
|
| 5. |
86900323
|
[2] |
NUT,#10 - 24
|
PA
|
| 6. |
9804278
|
[4] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 7. |
84387467
|
[1] |
BRACKET
|
NH
|
| 8. |
86594422
|
[1] |
SENSOR
|
NH
Tailgate
|
| 9. |
164995
|
[8] |
WASHER,32.5mm ID x 42.9mm OD x 4.38mm Thk
|
NH
|
| 10. |
374892
|
[4] |
CARRIAGE BOLT,M10 x 1.5 x 40mm, Cl 8.8
|
NH
|
| 11. |
9600196
|
[2] |
SPACER,32.23mm ID x 39.7mm OD x 29.98mm L
|
NH
Superseded by part number: 86636674
|
| 12. |
86624468
|
[1] |
SPACER,1.65" L x 5/16” Thk
|
NH
Tailgate Sensor
|
| 13. |
87399
|
[8] |
COTTER PIN,1/2 x 3 Bolt
|
GI
|
| 14. |
86900322
|
[2] |
SCREW,Phillips Drive, Truss HD, #10 - 24 x 1-1/4", SST
|
PA
|
| 15. |
166065
|
[2] |
PIN,25.4mm OD x 66.5mm L
|
NH
|
| 16. |
86554798
|
[1] |
PIN,31.7mm OD x 66mm L
|
NH
|
| 17. |
86554799
|
[1] |
ROD,1232.7mm L
|
PA
Superseded by part number: 86637292
|
| 18. |
64972
|
[4] |
WASHER,32.54mm ID x 50.8mm OD x 3.43mm Thk
|
NH
|
| 19. |
87367
|
[4] |
WASHER,1.06" ID x 2" OD x 0.13" Thk
|
PA
|
| 20. |
80700
|
[2] |
WASHER,0.56" ID x 1.38" OD x 0.11" Thk
|
NH
|
| 21. |
80679
|
[2] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 22. |
80702
|
[2] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 23. |
80756
|
[1] |
COTTER PIN,1/8" x 3/4"
|
NH
|
| 24. |
34019
|
[1] |
SPRING,Compression, 9/16" OD x 2-5/16" L
|
GI
|
| 25. |
26306
|
[2] |
DRIVE BUSHING,25.47mm ID x 31.82mm OD x 31.8mm L
|
NH
|
| 26. |
86546201
|
[2] |
PIN
|
PA
75mm L Superseded by part number: 86637276
|
| 26. |
47919326
|
[2] |
PIN
|
NH
90mm L
|
| 27. |
86977433
|
[2] |
SPACER,13.11mm ID x 19.05mm OD x 12.7mm Thk
|
PA
Superseded by part number: 86622618
|
| 28. |
86629541
|
[2] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 29. |
86516139
|
[3] |
CAUTION DECAL
|
NH
Pinch Hazard
|
| 30. |
86547711
|
[1] |
DECAL,SMV
|
NH
|
| 31. |
47361241
|
[1] |
WARNING DECAL
|
NH
Crush Hazard
|
