凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (55.511.AJ) - REAR LIGHT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
791 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84598552
|
[2] |
BRACKET
|
NH
Superseded by part number: 47936121
|
| 2. |
84239207
|
[2] |
TAIL LAMP,12V, 28W
|
WIC
Red
|
| 3. |
84239208
|
[2] |
LAMP,12V, 28W
|
WIC
Turn, Amber
|
| 4. |
322356
|
[8] |
BELLEVILLE WASHER,M5 Bolt Size x 12mm OD x 1.85mm Thk
|
ZED
|
| 5. |
84361277
|
[8] |
HEX SOC SCREW
|
SAS
#10-24 x 1-1/2 Superseded by part number: 463-11024
|
| 6. |
87304
|
[8] |
NUT,#10-24
|
BEL
|
