神钢零件查询(6D22) - MITSUBISHI DIESEL ENGINE - K912, K912LC, & K916 (1/83-12/06) (01-032) - OIL FILLER & OIL LEVEL GAUGE 020-510D Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
775 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAMH093024 | [1] | OIL PRESSURE GAUGE | KOBGAUGE, OIL LEVEL |
| 2. | VAME059055 | [1] | GUIDE | KOBGUIDE, OIL LEVEL GAUGE |
| 3. | VA3094290700 | [1] | STAY | KOBSTAY |
| 5. | VAMH021015 | [2] | CLAMP | KOBCLAMP Superseded by part number: 132398A1 |
| 6. | VAMH000999 | [1] | BOLT | KOBBOLT, FLANGE 6X12 |
| 7. | VAMF520005 | [1] | O-RING | KOBO-RING 10 Superseded by part number: 132399A1 |
| 9. | VA3001305900 | [1] | GASKET | KOBGASKET Superseded by part number: 132394A1 |
| 10. | VAMH000706 | [1] | SCREW | KOBBOLT, FLANGE 10X16 Superseded by part number: 132289A1 |
| 11. | VAMF241280 | [2] | SCREW | KOBBOLT, W/WSR 10X20, P=1.25 Superseded by part number: 132376A1 |
| 15. | VAME059043 | [1] | FILLER, OIL | |
| 16. | VAMD008784 | [1] | CAP | KOBOIL FILLER Superseded by part number: VA1250A015 |
| 17. | VA3009886400 | [1] | COVER | |
| 18. | VAMH035087 | [1] | GASKET | KOBGASKET Superseded by part number: 132396A1 |
| 19. | VAMH000713 | [2] | BOLT | KOBBOLT, FLANGE 10X20 |
| 20. | VAMF520411 | [1] | O-RING | KOBO-RING 75 |
| 21. | VAMH000843 | [2] | SCREW | KOBBOLT, FLANGE 12X25 Superseded by part number: 132385A1 |
| 23. | VAMH020175 | [1] | CLIP CLIP | CLIP CLIP |
| 24. | VAMH000999 | [2] | BOLT | KOBBOLT, FLANGE 6X12 |
| 31. | VAMH037760 | [1] | CAP COVER | KOBCAP, SEALING 15 Superseded by part number: 132367A1 |
