凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (55.630.AF[01]) - VAR - 726965 - WIRE HARNESS, TRACTOR CAB, YGN191545 AND PRIOR Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
273 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84566253
|
[1] |
WIRE HARNESS
|
NH
Cab, Incl 2 - 22
|
| 2. |
767456
|
[1] |
PLUG
|
NH
Superseded by part number: 87716289
|
| 3. |
87271930
|
[1] |
NUT
|
FAR
|
| 4. |
84420455
|
[1] |
LOCK WASHER,48mm ID x 45.8mm OD
|
ZED
|
| 5. |
787868
|
[1] |
BRACKET
|
NH
|
| 6. |
87612756
|
[1] |
CLAMP,25.4mm, Coat, 7.1mm Bolt Hole, P Type
|
PLO
|
| 7. |
617887
|
[1] |
HOOK
|
NH
|
| 8. |
322357
|
[1] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 9. |
9804276
|
[1] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 10. |
9706703
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
NH
|
| 11. |
47674223
|
[1] |
Uses 24
|
ELEC CONNECTOR,Female, 2 Cavities
|
| 12. |
87688712
|
[1] |
WIRE CONNECTOR,Female
|
BN
Uses 23
|
| 13. |
84277215
|
[1] |
|
ELEC CONNECTOR,Female, 8 Cavities
|
| 14. |
84074255
|
[1] |
CONTACT HOUSING,Male, 9 Pole
|
ZED
|
| 15. |
87675194
|
[1] |
MULTIPOLE CONNECTOR,Female, 3 Pole
|
SAS
|
| 16. |
84384515
|
[1] |
MULTIPOLE CONNECTOR,Female, 21 Cavities
|
NH
|
| 17. |
87688863
|
[1] |
CAP
|
BN
|
| 18. |
84277231
|
[1] |
|
LOCKING TAB,Wedge Lock
|
| 19. |
84068583
|
[1] |
PLUG,12 - 16 Ga, White
|
ZED
Superseded by part number: 87695652
|
| 20. |
84471900
|
[1] |
DUST CAP
|
RAC
|
| 21. |
87695199
|
[1] |
SPACER
|
SAS
|
| 22. |
87696197
|
[1] |
NUT
|
CUR
|
| 23. |
9623775
|
[1] |
FUSE,5 Amp
|
NH
Superseded by part number: 87693742
|
| 24. |
9846342
|
[1] |
FUSE,25A
|
BEL
Superseded by part number: D9ZB14A094FA
|
| 25. |
87696199
|
[1] |
SEALING RING
|
CUR
|
