神钢零件查询(6D22) - MITSUBISHI DIESEL ENGINE - K912, K912LC, & K916 (1/83-12/06) (02-003) - WATER PIPE & THERMOSTAT 030-120C Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
192 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME059415 | [1] | CASE, THERMOSTAT, M1 ONLY | |
| . . | VAME059415 | [1] | CASE, THERMOSTAT, M2 ONLY | |
| 2-3. | VAME999306 | [1] | THERMOSTAT | KOBTHERMOSTAT KIT 76.5C |
| 2. | VAME055228 | [1] | THERMOSTAT | KOBTHERMOSTAT 76.5C Superseded by part number: VAME999306 |
| 3. | VAME055402 | [1] | GASKET | KOB Superseded by part number: 134824A1 |
| 4-5. | VAME999306 | [1] | THERMOSTAT | KOBTHERMOSTAT KIT 76.5C |
| 4. | VAME055228 | [1] | THERMOSTAT | KOB76.5C Superseded by part number: VAME999306 |
| 5. | VAME055402 | [1] | GASKET | KOB Superseded by part number: 134824A1 |
| 6. | VAME059420 | [1] | COVER | KOBCOVER, THERMOSTAT, M1 ONLY |
| . . | VAME059420 | [1] | COVER | KOBCOVER, THERMOSTAT, M2 ONLY |
| 6A. | VAMH000714 | [6] | BOLT | KOBBOLT, FLANGE 10X25, M1 ONLY |
| . . | VAMH000714 | [6] | BOLT | KOBBOLT, FLANGE 10X25, M2 ONLY |
| 7. | VAMF406285 | [1] | STUD | KOBSTUD 10X22 Superseded by part number: 134827A1 |
| 8. | VAMF434105 | [2] | NUT | KOBNUT, FLANGE 10 |
| 8A. | VAMF406285 | [1] | STUD | KOBSTUD 10X22 Superseded by part number: 134827A1 |
| 9. | VAMF520409 | [1] | O-RING | KOBO-RING 65 Superseded by part number: VAF315306500 |
| 10. | VAM0001300 | [1] | PLUG | KOBPLUG, DRAIN 16 |
| . . | VAMF660066 | [1] | GASKET | KOBGASKET 16 Superseded by part number: VAF420216000 |
| 14. | VAME059417 | [1] | PIPE | KOBM1 ONLY |
| . . | VAME059417 | [1] | PIPE | KOBM2 ONLY |
| 18. | VA3094600500 | [6] | GASKET | KOBWATER OUTLET PIPE Superseded by part number: VAME150855 |
| 19. | VAMH000708 | [12] | BOLT | KOBBOLT, FLANGE 10X45, M1 ONLY |
| . . | VAMH000708 | [12] | BOLT | KOBBOLT, FLANGE 10X45, M2 ONLY |
| 20. | VAMF665004 | [1] | PLUG PLUG 14, M1 ONLY | PLUG PLUG 14, M1 ONLY |
| . . | VAMF660065 | [1] | GASKET | KOBGASKET 14, M1 ONLY |
| 21. | VAME059359 | [1] | FLEXIBLE HOSE | KOB Superseded by part number: 134949A1 |
| 22. | VAMH020382 | [2] | HOSE CLAMP | KOBCLIP,HOSE 55 Superseded by part number: MH020382 |
