凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (60.220.AN[05]) - RADIAL PIN CLUTCH ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
981 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47578545
|
[1] |
CLUTCH
|
NH
Radial Pin, Incl 2 - 11
|
| 2. |
700703406
|
[21] |
CAM
|
L
Superseded by part number: 84819985
|
| 3. |
386510
|
[21] |
SPRING,Compression, 13mm OD X 13.2mm L
|
NH
External
|
| 4. |
386511
|
[21] |
SPRING,Compression, 7mm OD x 13.2mm L
|
PA
Internal
|
| 5. |
86636027
|
[1] |
DISC
|
PA
|
| 6. |
80300633
|
[1] |
SNAP RING,M80, Int
|
ZED
Superseded by part number: 300633
|
| 7. |
86634290
|
[1] |
SEALING RING,58.5mm ID x 84mm OD x 6mm Thk
|
GI
|
| 8. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Hub, Incl in 1
|
| 9. |
84447449
|
[2] |
LUBE NIPPLE,M8.2 x 1
|
ZED
|
| 10. |
84182666
|
[1] |
BUSHING
|
NH
|
