纽荷兰零件查询(CV900) - VIBRATORY ROLLER (9/01-) (09-001-00[01]) - HYDRAULIC CIRCUIT, BRAKING New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
948 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND031235 | [1] | BLOCK | STA |
| 3. | ND052874 | [2] | HYD CONNECTOR | STA |
| 6. | 72190667 | [1] | BLOCK | STA Superseded by part number: ND102242 |
| 7. | ND090925 | [1] | VALVE | STA24V |
| 11. | ND062180 | [1] | HYD CONNECTOR | STA |
| 12. | ND062154 | [1] | HYD CONNECTOR | STA |
| 13. | ND062156 | [1] | HYD CONNECTOR | STA |
| 14. | ND062188 | [1] | HYD CONNECTOR | STA |
| 15. | ND062217 | [2] | HYD CONNECTOR | STA |
| 21. | ND062008 | [8] | HALF-COLLAR | STA |
| 23. | ND079933 | [4] | O-RING | STA |
| 24. | ND079934 | [3] | O-RING | STA |
| 25. | ND079939 | [2] | O-RING | STA |
| 26. | ND102236 | [1] | FLEXIBLE HOSE | STA |
| 28. | ND102235 | [1] | FLEXIBLE HOSE | STA200mm |
| 29. | ND102240 | [1] | HOSE,500.00 mm | STA Superseded by part number: ND135014 |
| 32. | ND104853 | [1] | HOSE,850.00 mm | STA |
| 33. | ND104849 | [1] | HOSE,100.00 mm | STA |
| 34. | ND104854 | [1] | HOSE,1450.00 mm | STA |
| 35. | ND104851 | [1] | HOSE,470.00 mm | STA |
| 44. | ND034063 | [8] | BOLT | STA |
| 45. | ND034064 | [4] | BOLT | STA |
| 46. | ND034059 | [16] | BOLT | STA |
