神钢零件查询(6D22) - MITSUBISHI DIESEL ENGINE - K912, K912LC, & K916 (1/83-12/06) (05-001) - FUEL INJECTION PUMP DRIVE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
133 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-18. | VAME058068 | [1] | ROLLER BEARING | KOBINJECTION PUMP Superseded by part number: VAME158176 |
| 1. | VAME057119 | [1] | CRANK CASE ASSY, MITSUBISHI PART NO. (ME713000) | CRANK CASE ASSY, MITSUBISHI PART NO. (ME713000) |
| 4-5. | VAME713230 | [1] | HOLDER | KOB |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONHOLDER, BRG |
| 5. | VA3097520600 | [1] | PISTON RING SET | KOBOIL, SEAL, MITSUBISHI PART NO. (ME713004) |
| 8. | VA3092599100 | [1] | SHAFT, PUMP DRIVE SHAFT | SHAFT, PUMP DRIVE SHAFT |
| 9. | VA3097520400 | [1] | O-RING | KOBO-RING, MITSUBISHI PART NO. (ME713002) Superseded by part number: 132630A1 |
| 10. | VAMF101256 | [4] | BOLT 8X22 | |
| . . | VA0334013024 | [4] | WASHER SPRI WASHER, SPG 8, MITSUBISHI PART NO. (MF450405) | WASHER SPRI WASHER, SPG 8, MITSUBISHI PART NO. (MF450405) |
| 14. | VA3097524600 | [1] | COLLAR CLAMP | KOBCOLLAR, MITSUBISHI PART NO. (ME713030) Superseded by part number: 132559A1 |
| 15. | VAME713086 | [4] | BOLT 10X30, MITSUBISHI PART NO. (MF129648) | |
| . . | VAMF450406 | [4] | WASHER | KOBWASHER, SPG 10 |
| 16. | VA3092599200 | [1] | COVER | |
| 17. | VA3092599300 | [1] | GASKET | KOBGASKET Superseded by part number: VAME737074 |
| 18. | VAME713196 | [1] | UNIVERSAL JOINT | KOBJOINT, MITSUBISHI PART NO. (MH038303) |
| 20. | VAMH035606 | [1] | O-RING | KOBO-RING |
| 21. | VAMS476136 | [1] | WOODRUFF KEY | KOBKEY, WOODRUFF 5X22 |
| 22. | VAMH000713 | [1] | BOLT | KOBBOLT, FLANGE 10X20 |
| 23. | VAMH000724 | [5] | SCREW | KOBBOLT, FLANGE 10X85 Superseded by part number: 132669A1 |
| 25. | VAM0001300 | [1] | PLUG | KOBPLUG, DRAIN 16 |
| . . | VAMF660066 | [1] | GASKET | KOBGASKET 16 Superseded by part number: VAF420216000 |
