凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (60.220.CC[02]) - VAR - 726817 - 1.8M TINE WINDGUARD, OVERSHOT FEEDER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
753 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84425604
|
[2] |
ARM
|
NH
|
| 2. |
84563993
|
[2] |
SPACER,10.31mm ID x 18.24mm OD x 33.53mm L
|
NH
|
| 3. |
84412946
|
[1] |
WINDGUARD
|
NH
1.8M OSR Tine Superseded by part number: 48008883
|
| 4. |
47361097
|
[2] |
SPACER,20mm ID x 34.9mm OD x 31mm L
|
NH
|
| 5. |
133095
|
[2] |
SPACER,10.32mm ID x 15.85mm OD x 7.9mm L
|
NH
|
| 6. |
80702
|
[8] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 7. |
9804262
|
[2] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 8. |
9804277
|
[6] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 9. |
86508947
|
[2] |
LINCH PIN,18.8mm OD
|
NH
|
| 10. |
87027237
|
[2] |
CHAIN,18 Links x 37.2mm = 670mm L
|
PA
Superseded by part number: 87055684
|
| 11. |
9637692
|
[2] |
NUT,3/8"-16, GB
|
NH
|
| 12. |
88546
|
[2] |
BOLT,Hex, 3/8" - 16 x 2 1/4", Gr 5
|
NH
|
| 13. |
120069
|
[2] |
BOLT,M10 x 1.5 x 56.58mm OAL, Cl 8.8
|
NH
|
| 14. |
84495729
|
[1] |
WINDGUARD
|
NH
|
| 15. |
87043879
|
[2] |
RETAINER
|
PA
|
| 16. |
308761
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
