现代零件查询R170W-7A MAIN CONTROL VALVE(3/4, TYPE 2, #0319-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
229 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
MAIN CONTROL VALVE
|
|
| N1. |
31N4-17610
|
[1] |
HOUSING(P1)
|
|
| 10. |
31N4-17670
|
[1] |
BOOM SPOOL ASS'Y
|
|
| 11. |
31N4-17700
|
[1] |
ARM2 SPOOL ASS'Y
|
|
| 12. |
31N4-17720
|
[1] |
ARM REGEN SPOOL ASS'Y
|
|
| 13. |
31N4-17740
|
[1] |
BUCKET SPOOL ASS'Y
|
|
| 14. |
31N4-17650
|
[1] |
DOZER SPOOL ASS'Y
|
|
| 16. |
31N4-17750
|
[1] |
HOLDING V/V ASS'Y
|
|
| 17. |
31N4-17780
|
[1] |
REGEN V/V ASS'Y
|
|
| 20. |
31N4-17870
|
[2] |
NEGACON VALVE COMP
|
|
| 32. |
31N4-17900
|
[1] |
PLUG KIT
|
|
| 33. |
31N8-18680
|
[2] |
PLUG
|
|
| 34. |
31N4-17930
|
[4] |
PILOT COVER A
|
|
| 35. |
31N4-17940
|
[5] |
PILOT COVER B1
|
|
| 39. |
31N8-18530
|
[1] |
POPPET-SIGNAL
|
|
| 42. |
31N8-18540
|
[1] |
SPRING-SIGNAL
|
|
| 46. |
31N4-18610
|
[10] |
O-RING
|
|
| 50. |
S107-060404
|
[16] |
BOLT-SOCKET
|
|
| 55. |
S107-121204
|
[7] |
BOLT-SOCKET
|
|
| 56. |
S411-060006
|
[16] |
WASHER-SPRING
|
|
| N58. |
31N8-19410
|
[1] |
NAME PLATE
|
|
| N59. |
31N8-19490
|
[2] |
REVET-SCREW TYPE
|
|
| 63. |
31N8-19460
|
[10] |
CAP-DUST
|
|
| N. |
@
|
[AR] |
NOT INDIVIDUALLY SUPPLIED
|
|
