神钢零件查询(6D22) - MITSUBISHI DIESEL ENGINE - K912, K912LC, & K916 (1/83-12/06) (08-002) - CYLINDER BLOCK REPAIR KIT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
265 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-26. | VAME997037 | [1] | CRANKCASE | KOBASSY, 6D22,22T Superseded by part number: 132276A1 |
| 1. | VAME051631 | [1] | CRANKCASE, A MARK | |
| 2. | VAME051073 | [1] | CAP, BRG FR | |
| 3. | VAME051074 | [1] | CAP, BRG NO.2 | |
| 4. | VAME051075 | [4] | CAP, BRG M1 | |
| 5. | VAME051196 | [1] | CAP, BRG RE | |
| 6. | VAME061330 | [14] | SCREW | KOB Superseded by part number: 132340A1 |
| 7. | VAME051633 | [6] | LINER, ENGINE CYLIND | KOBB SIZE Superseded by part number: 132313A1 |
| 8. | VAME051375 | [12] | O-RING | KOB Superseded by part number: VAME151038 |
| 9. | VA3090722300 | [6] | SEAL KIT | KOB Superseded by part number: 132311A1 |
| 10. | VA3110702401 | [12] | O-RING | KOB Superseded by part number: 3110702401 |
| 11. | VAMS666137 | [1] | CAP | KOBCAP, SEALING |
| 12. | VAMH007009 | [2] | PIN | KOBPIN, DOWEL 8 |
| 13. | VAME051672 | [1] | BUSHING | KOBBUSHING, CAMSHAFT NO.1 Superseded by part number: 132333A1 |
| 14. | VAME051673 | [1] | BUSHING | KOBBUSHING, CAMSHAFT NO.2 |
| 15. | VAME051674 | [1] | BEARING | KOBBUSHING, CAMSHAFT NO.3 Superseded by part number: 132335A1 |
| 16. | VAME051675 | [1] | BEARING | KOBBUSHING, CAMSHAFT NO.4 Superseded by part number: 132336A1 |
| 17. | VAME051676 | [1] | BEARING | KOBBUSHING, CAMSHAFT NO.5 Superseded by part number: 132337A1 |
| 18. | VAME051677 | [1] | BEARING | KOBBUSHING, CAMSHAFT NO.6 Superseded by part number: 132338A1 |
| 19. | VAME051678 | [1] | BUSHING | KOBBUSHING, CAMSHAFT NO.7 Superseded by part number: 132339A1 |
| 22. | VAMHC07011 | [2] | PIN, DOWEL 12 | |
| 23. | VAMF472405 | [2] | DOWEL | KOBPIN, DOWEL 10, FOR INJ/P Superseded by part number: 132323A1 |
| 24. | VAMF472406 | [2] | PIN | KOBPIN, DOWEL 12 ,FOR FR COV |
| 25. | VAMH012037 | [6] | PIN | KOBPIN, SPG 5X10 Superseded by part number: 132322A1 |
| 26. | VAME040252 | [3] | HANGER | SMHANGER |
