凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (60.260.CC[05]) - VAR - 726914 - ROTOR FEEDER MOUNTING, DROP FLOOR Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
157 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87016
|
[4] |
WASHER,0.41" ID x 0.81" OD x 0.07" Thk
|
NH
|
| 2. |
86580291
|
[4] |
ADAPTER,1/8" - 27 x 1/4" - 28
|
NH
|
| 3. |
48564
|
[6] |
90 ELBOW,90 Degree, 11/16" x 5/8", 1/8" NPT
|
NH
|
| 4. |
87014413
|
[1] |
TUBE,4.80 mm OD x 1850 mm L
|
PA
|
| 5. |
140045
|
[9] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 6. |
86590413
|
[2] |
BASE,15.87mm W x 22.22mm OAL x 9.9mm Thk
|
ZED
|
| 7. |
86566989
|
[4] |
CABLE TIE,208mm L
|
ZED
|
| 8. |
84385577
|
[2] |
FLAP
|
PLO
Rubber
|
| 9. |
84425466
|
[2] |
PLATE
|
PLO
|
| 10. |
445394
|
[2] |
RIVET,Pop, 3/16" x 1/2" OAL
|
ZED
Superseded by part number: 151-573
|
| 11. |
86633356
|
[10] |
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
|
ZED
|
| 12. |
9804261
|
[4] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 13. |
11787
|
[2] |
FITTING,3/8"-24 Fem x 1/8" NPT
|
NH
Superseded by part number: 84341119, 84341119, 87426476
|
| 14. |
80702
|
[4] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 15. |
9804278
|
[10] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 16. |
100037
|
[4] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 17. |
80280397
|
[4] |
LUBE NIPPLE,45 Degree, Female 1/8" NPTF
|
GI
|
| 18. |
140021
|
[2] |
WASHER,22mm ID x 37mm OD x 3mm Thk
|
NH
|
