纽荷兰零件查询(CV900) - VIBRATORY ROLLER (9/01-) (12-022-04[01]) - HEATER UNIT New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
268 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND053485 | [1] | SUPPORT | STA |
| 3. | ND075046 | [1] | HOSE,2500.00 mm | STA |
| 4. | ND075048 | [1] | FLEXIBLE HOSE | STA3500 mm |
| 5. | ND062022 | [2] | PROTECTING COVER | STA500 mm |
| 6. | ND062193 | [1] | HYD CONNECTOR | STA |
| 7. | ND062194 | [1] | HYD CONNECTOR | STA |
| 8. | ND062195 | [2] | TUBE | STA |
| 9. | ND069479 | [2] | CLAMP | STA16-25 |
| 10. | ND064809 | [1] | CLAMP | STA |
| 13. | ND021312 | [1] | BOLT | STAM12 x 40 |
| 14. | ND024234 | [2] | BOLT | STAM6 x 30 |
| 15. | ND029309 | [2] | SPRING WASHER | STAID 6,1 |
