| 1. |
84561410
|
[1] |
ROLL
|
PLO
Upper
|
| 2. |
47965028
|
[1] |
Nose
|
ROLL
|
| 3. |
47450935
|
[1] |
ROLL
|
NH
Rubber Guide
|
| 4. |
84600572
|
[1] |
ROLL
|
PLO
Lower, Incl 22
|
| 5. |
47670880
|
[1] |
ROLL
|
PLO
Tailgate Chop, Incl 22
|
| 6. |
47452964
|
[1] |
SHAFT
|
PLO
Tailgate Chop, Incl 23
|
| 7. |
87023400
|
[2] |
SUPPORT
|
PA
|
| 8. |
86516321
|
[2] |
SUPPORT
|
NH
Superseded by part number: 87654791
|
| 9. |
47973458
|
[1] |
SCRAPER
|
NH
Angle
|
| 10. |
9804278
|
[4] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 11. |
86512446
|
[4] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 12. |
84405459
|
[2] |
BALL BEARING,40mm ID
|
PLO
|
| 13. |
47538078
|
[4] |
BEARING ASSY,40mm ID x 60.3mm H
|
PLO
|
| 14. |
80714
|
[2] |
LUBE NIPPLE,1/4"-28 NPT x .54" lg
|
PA
Superseded by part number: 87414
|
| 15. |
56513
|
[4] |
PLUG,Hex Soc, 1/8" - 27 NPT
|
NH
Superseded by part number: 86637724
|
| 16. |
9670288
|
[8] |
BOLT,Hex, M12 x 35mm, Cl 8.8
|
PA
|
| 17. |
65319
|
[2] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 18. |
29684
|
[2] |
WASHER,13.5mm ID x 50.8mm OD x 5.52mm Thk
|
NH
|
| 19. |
9706702
|
[2] |
BOLT,Hex, M12 x 1.75 x 50mm, Cl 8.8
|
NH
|
| 20. |
328754
|
[8] |
CARRIAGE BOLT,M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 21. |
9804279
|
[8] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 22. |
84259867
|
[4] |
BALL BEARING,38.1mm ID x 80mm OD x 22mm W
|
PLO
|
| 23. |
130045
|
[2] |
PIN,5mm OD x 26mm L, Slotted
|
NH
|
