神钢零件查询(6D22) - MITSUBISHI DIESEL ENGINE - K912, K912LC, & K916 (1/83-12/06) (03-018) - FUEL INJECTION NOZZLE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
471 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-13. | VAME059621 | [6] | NOZZLE | KOBASSY, M0 ONLY |
| . . | VAME056275 | [6] | NOZZLE | KOBM2 ONLY Superseded by part number: 240109A1 |
| . . | VAME054473 | [6] | M4 ONLY | |
| . . | VAME050883 | [6] | NOZZLE | KOBM9 ONLY |
| 1-12. | VAME705432 | [6] | NOZZLE HOLDER ASSY, M0 ONLY | |
| . . | VAME705431 | [6] | NOZZLE HOLDER | KOBM2 & M4 ONLY Superseded by part number: 240125A1 |
| . . | VAME705441 | [6] | NOZZLE | KOBM9 ONLY Superseded by part number: 135151A1 |
| 1. | VAME705400 | [6] | SCREW | KOBEYE Superseded by part number: 77270082, 134650A1 |
| 2. | VAME705389 | [12] | PACKING | KOB Superseded by part number: 134686A1 |
| 3. | VAME705427 | [6] | NUT | KOBNUT, CAP, M0 & M9 ONLY Superseded by part number: 134714A1 |
| . . | VAME705424 | [6] | M2 & M4 ONLY | |
| 3A. | VAME705416 | [6] | NUT, M2 & M4 ONLY | |
| 4. | VAME705391 | [6] | GASKET | KOBM0 & M9 ONLY Superseded by part number: 134652A1 |
| . . | VAME717881 | [6] | GASKET | KOBM2 & M4 ONLY |
| 5. | VAME705404 | [6] | SCREW ADJUS M0 & M7 ONLY | SCREW ADJUS M0 & M7 ONLY |
| . . | VAME705415 | [6] | M2 & M4 ONLY | |
| 5A. | VAME705413 | [6] | SCREW, SET, M2 & M4 ONLY | |
| 5B. | VAME705412 | [6] | SPACER, M2 & M4 ONLY | |
| 5C. | VAMD603631 | [6] | SHIM, M2 & M4 ONLY | |
| 6. | VAME705405 | [6] | SPRING NOZZLE, M0 ONLY | SPRING NOZZLE, M0 ONLY |
| . . | VAME705409 | [6] | SPRING | KOBM9 ONLY Superseded by part number: 133275A1 |
| . . | VAME705411 | [6] | M2 & M4 ONLY | |
| 6A. | VAME705418 | [6] | SPRING, NOZZLE, M2 & M4 ONL | |
| 6B. | VAMD603631 | [6] | SHIM, M2 & M4 ONLY | |
| 7. | VAME705406 | [6] | PUSH ROD | KOBM0 & M9 ONLY Superseded by part number: 134708A1 |
| . . | VAME705410 | [6] | M2 & M4 ONLY | |
| 7A. | VAME705414 | [6] | ROD, PUSH, M2 & M4 ONLY | |
| 8. | VAME705401 | [6] | HYD CONNECTOR | KOBINLET |
| 9. | VAME705390 | [6] | GASKET | KOB Superseded by part number: VA0293005070 |
| 10. | NSS | [6] | NOT SOLD SEPARAT | CONBODY, NOZZLE |
| 11. | VAME705407 | [12] | PIN | KOB Superseded by part number: 77270085, 134711A1 |
| 12. | VAME705402 | [6] | NUT | KOBNUT, RETAINING |
| 13. | VAME705429 | [6] | NOZZLE | KOBTIP, 4-0.37, M0 & M2 ONLY |
| . . | VAME705435 | [6] | NOZZLE | KOB5-0.36, M4 & M9 ONLY Superseded by part number: 132284A1 |
| 14. | VA3096102200 | [6] | O-RING | KOBSEAL, DUST Superseded by part number: 134649A1 |
| 15. | VA3096102300 | [6] | O-RING | KOBGASKET, NOZZLE TIP |
| 16. | VAMH000657 | [12] | SCREW | KOBBOLT Superseded by part number: 134715A1 |
