神钢零件查询(6D22-T) - MITSUBISHI DIESEL ENGINE - K909A, K912A, K916, & K935 (1/76-12/06) (01-010) - CRANKSHAFT & PULLEY Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
748 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D221CT-K509 | [1] | CRANK SHAFT & PULLEY, M4 | |
| . . | 6D221CT-KS04 | [1] | CRANK SHAFT & PULLEY, M4 | |
| . . | 6D221CT-KS03 | [1] | CRANK SHAFT & PULLEY, M4 | |
| . . | 6D221CT-KS01 | [1] | CRANK SHAFT & PULLEY, M4 | |
| . . | 6D221CZ-KS0A | [1] | CRANK SHAFT & PULLEY, M4 | |
| . . | 6D221CZ-KS06 | [1] | CRANK SHAFT & PULLEY, M4 | |
| . . | 60221CZ-KS09 | [1] | CRANK SHAFT & PULLEY, M4 | |
| . . | 6D221CZ-KS07 | [1] | CRANK SHAFT & PULLEY, M4 | |
| . . | 6D221C2-KS04 | [1] | CRANK SHAFT & PULLEY, M4 | |
| . . | 6D221CT-KS0B | [1] | CRANK SHAFT & PULLEY, M0 | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONCRANKSHAFT, CF GN450-820A |
| 2. | VAMH012026 | [1] | PIN | KOBPIN, DOWEL |
| 3. | VAMF472407 | [2] | PIN | KOBPIN, DOWEL 14 |
| 10. | VAME058336 | [1] | PULLEY | KOBCRANKSHAFT, D192 CX2 |
| . . | VAME058318 | [1] | PULLEY | KOBD192 CX2 |
| 11. | VAMH000377 | [6] | BOLT | KOBBOLT, FLANGE, 14X35 |
