神钢零件查询(6D22-T) - MITSUBISHI DIESEL ENGINE - K909A, K912A, K916, & K935 (1/76-12/06) (01-012) - TIMING GEAR Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
550 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D221CT-KS0B | [1] | TIMING GEAR, M0 | |
| . . | 6D221CT-KS09 | [1] | TIMING GEAR, M0 | |
| . . | 6D221CT-KS04 | [1] | TIMING GEAR, M0 | |
| . . | 6D221CT-KS03 | [1] | TIMING GEAR, M0 | |
| . . | 6D221CT-KS01 | [1] | TIMING GEAR, M0 | |
| . . | 6D222 ALL | [1] | TIMING GEAR, M0 | |
| 1. | VAME062311 | [1] | GEAR CRANKSHAFT, Z=63 | GEAR CRANKSHAFT, Z=63 |
| 2-5. | VAME062842 | [1] | GEAR | KOBIDLER, ASSY |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONGEAR, A IDLER, Z=33 |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONGEAR,B IDLER, Z=66 |
| 4. | VAME062905 | [1] | BUSHING | KOB Superseded by part number: 132529A1 |
| 5. | VAMS476135 | [1] | KEY | KOBKEY, WOODRUFF, 5X19 Superseded by part number: 132499A1 |
| 6. | VA3092311600 | [2] | IDLER SHAFT SHAFT, IDLER | IDLER SHAFT SHAFT, IDLER |
| 8. | VAMH012037 | [2] | PIN | KOBPIN, SPG, 5.4X10 Superseded by part number: 132322A1 |
| 10-11. | VAME052369 | [1] | GEAR ASSY IDLER | GEAR ASSY IDLER |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONGEAR, C IDLER, Z=68 |
| 11. | VAME062905 | [2] | BUSHING | KOB Superseded by part number: 132529A1 |
| 12. | VA3092312300 | [2] | BOLT BOLT,IDLER SHAFT | BOLT BOLT,IDLER SHAFT |
| 14. | VAME062326 | [2] | THRUST PLATE | KOBPLATE,THRUST |
| 15. | VAME062573 | [2] | COLLAR CLAMP | KOBCOLLAR Superseded by part number: 132541A1 |
| 17. | VAMF430009 | [2] | NUT | KOBNUT 16 |
| 19. | VAMF520583 | [2] | O-RING | KOBO-RING 35 |
| 21. | VA3112304100 | [2] | O-RING | KOBO-RING 15 Superseded by part number: 132546A1 |
| 22. | VAME051184 | [1] | GEAR GEAR,CAMSHAFT Z=63 | GEAR GEAR,CAMSHAFT Z=63 |
| 23. | VAMH004074 | [1] | NUT | KOBNUT |
| 24. | VAME062323 | [1] | WASHER | KOBWASHER,LOCK |
| 25-25A. | VAME052538 | [1] | INJECTION PUMP GEAR ASSY | |
| 25. | VAME052537 | [1] | GEAR | KOBGEAR,I/P Z=63 |
| 25A. | VAMF472402 | [1] | PIN | KOBPIN,DOWEL |
| 26. | VAME052602 | [1] | PLATE | KOBPLATE,SENSOR |
| 27. | VAMH004075 | [1] | NUT | KOBNUT |
| 28. | VA3117502109 | [1] | WASHER | KOBWASHER,LOCK |
| 29. | VA3090702900 | [1] | PLUG | KOBOIL SPRAY Superseded by part number: 132538A1 |
