纽荷兰零件查询(D125C LT) - CRAWLER DOZER - TIER 4A (10/13-) (10.310.AA[01]) - AFTERCOOLER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
429 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 84588264 | [1] | COOLER ASSY. | BURCharge Air |
| 2. | 84481483 | [2] | SEAL | BURFoam |
| 3. | L115549 | [8] | CLAMP,69.85mm - 92.08mm | CASHose |
| 4. | 87340284 | [2] | INTAKE AIR HOSE,76.20mm ID x 129mm L | FARCharge |
| 5. | 84481460 | [1] | RIGID TUBE | BURCac, Left Hand |
| 6. | 84570290 | [1] | INTAKE AIR HOSE,76.2mm ID x 221.7mm L | BURCac |
| 7. | 217-402 | [1] | PLUG,Hex Hd, 1/8"-27 NPTF | CAS Superseded by part number: 88071 |
| 8. | 84570428 | [1] | AIR INTAKE TUBE | BURCac, Right Hand |
| 9. | J883284 | [1] | O-RING,0.07" Thk x 2.364" ID, -36 | CASSeal Superseded by part number: J883284AM |
| 10. | J069053 | [1] | CLAMP,66.54mm ID | LTurbo Outlet |
| 11. | J918685 | [1] | PIPE | CASTurbo Outlet Air |
