斗山零件查询GUARD RAIL DX225LC (S/N 5433~) Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
730 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
110508-09493
|
[-] |
|
|
| 1. |
101582-00290
|
[1] |
|
|
| 2. |
101582-00291
|
[1] |
|
|
| 3. |
S0560666
|
[16] |
BOLT
|
|
| 4. |
S5102703
|
[16] |
WASHER
|
|
| 51. |
450103-00739
|
[1] |
|
|
| 51. |
450103-00739A
|
[1] |
|
|
| 51. |
450103-00337
|
[1] |
|
|
| 51. |
450103-00337A
|
[1] |
|
|
| 51-1. |
450103-00337A
|
[1] |
|
|
| 51-1. |
450103-00337B
|
[1] |
|
|
| 51-2. |
473-00033
|
[1] |
COVER
|
|
| 51-3. |
S8011450
|
[1] |
O-RING
|
|
| 51-4. |
S0512066
|
[1] |
. BOLT
|
|
| 51-5. |
120804-00076
|
[1] |
WASHER
|
|
| 61. |
450105-00403
|
[1] |
|
|
| 61. |
450105-00927
|
[1] |
|
|
| 61-1. |
450105-00403B
|
[1] |
|
|
| 61-2. |
110508-30345
|
[1] |
|
|
| 61-3. |
110508-30346
|
[1] |
|
|
| 61-4. |
420218-00112A
|
[1] |
|
|
| 61-5. |
S8011850
|
[1] |
O-RING
|
|
| 61-6. |
S8011650
|
[1] |
O-RING
|
|
| 61-7. |
S8011200
|
[1] |
O-RING
|
|
| 61-8. |
S0512066
|
[18] |
. BOLT
|
|
| 61-9. |
120804-00076
|
[18] |
WASHER
|
|
