凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (68.180.BB[01]) - TWINE KNIFE, P.I.N. YGN190998 AND PRIOR Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
576 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47438703
|
[1] |
SUPPORT
|
NH
|
| 2. |
84300403
|
[1] |
MOUNT
|
NH
|
| 3. |
617945
|
[1] |
KNIFE SECTION
|
NH
Twine
|
| 4. |
84235144
|
[1] |
ROD
|
NH
|
| 5. |
47501977
|
[1] |
SHIELD
|
NH
Superseded by part number: 47816936
|
| 6. |
86512439
|
[4] |
CARRIAGE BOLT,M6 x 16mm, Cl 8.8
|
NH
|
| 7. |
353308
|
[2] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| 8. |
378244
|
[3] |
WASHER,10.5mm ID x 24mm OD x 2mm Thk
|
NH
|
| 9. |
80756
|
[3] |
COTTER PIN,1/8" x 3/4"
|
NH
|
| 10. |
226829
|
[1] |
SPRING,Compression, 19.05mm OD x 77.72mm OD
|
NH
|
| 11. |
9804258
|
[3] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 12. |
9804276
|
[2] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 13. |
9804277
|
[1] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 14. |
86622500
|
[1] |
WASHER,13.49mm ID x 22.2mm OD x 1.36mm Thk
|
PA
|
