纽荷兰零件查询(D125C LT) - CRAWLER DOZER - TIER 4A (10/13-) (10.500.AA[02]) - DEF TANK New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
146 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 47462645 | [1] | RESERVOIR | BURDef Tank Incl 3 - 6 Superseded by part number: 47672724 |
| 2. | 84171379 | [1] | SENDER UNIT | RAC |
| 3. | 84284896 | [1] | DECAL | ZED |
| 4. | 84180429 | [1] | BUSHING | BASOuter, Sender Unit Urea |
| 5. | 84180430 | [1] | BUSHING | BASInner, Sender Unit Urea |
| 6. | 87302880 | [4] | SPACER,13.5mm ID x 19mm OD x 30.2mm L | CAS3/4 Tube X 30.18mm Stl |
| 7. | 495-11028 | [3] | WASHER,1/4", SAE | CAS Superseded by part number: 87361, 72187256 |
| 8. | 614-6020 | [3] | BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd | CAS Superseded by part number: 120100 |
| 9. | 393392 | [3] | LOCK NUT,M6 x 1.0, Cl 8 | WIN Superseded by part number: V43393 |
| 10. | 9515003 | [2] | BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9 | BHB |
| 11. | 47422308 | [1] | BRACKET | BURFill |
| 12. | 84206552 | [1] | FILLER CAP | BASUrea Tank |
| 13. | 84246766 | [4] | HEX SOC SCREW,M4 x 12mm, SST | BN |
| 14. | 84315307 | [1] | FILLER | FAR |
| 15. | 84387525 | [1] | HOSE ASSY. | BURDEF REAR, For Filter See Callout 18 |
| 16. | 87483158 | [1] | NECK FILLER | RACUrea Tank |
| 17. | L115548 | [2] | CLAMP,57.15mm - 79.38mm | CASConstant Torque |
| 18. | 84153651 | [1] | FILTER SCREEN | FAR |
