| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 3E-7424 | [1] | CLAMP-HOSE | |
| 2. | 171-3885Y | [1] | AIR CLEANER GP | |
| 3. | 171-3886 | [1] | BRACKET AS | |
| 6N-0508 | [2] | SPACER(11.13X22.23X40.64-MM THK) | ||
| 4. | 220-8496 | [1] | SEAL | |
| 5. | 7X-7729 | [4] | WASHER(11X25X3-MM THK) | |
| 6. | 8T-4121 | [4] | WASHER-HARD(11X21X2.5-MM THK) | |
| 7. | 8T-4133M | [4] | NUT(M10X1.5-THD) | |
| 8. | 8T-4136M | [6] | BOLT(M10X1.5X25-MM) | |
| 9. | 8T-5005M | [2] | BOLT(M10X1.5X70-MM) | |
| M | METRIC PART | |||
| Y | SEPARATE ILLUSTRATION | |||
