凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (88.100.60[03]) - DIA KIT, ROLLER WINDGUARD, 1.8M Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
535 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84554685
|
[1] |
DIA KIT, HARVESTER
|
NH
1.8M Roller Windguard, Incl 2 - 12
|
| 2. |
84555289
|
[1] |
INSTRUCTION
|
NH
|
| 3. |
47507709
|
[2] |
SPACER,24.88mm ID x 41mm OD x 13mm Thk
|
PLO
|
| 4. |
84426074
|
[2] |
ARM
|
NH
|
| 5. |
86603075
|
[2] |
FLANGE,Bearing, 52.01 mm ID x 95.3 mm OD x 8.7 mm
|
NH
|
| 6. |
325103
|
[2] |
BALL BEARING,25mm ID x 52mm OD x 15mm W
|
ZED
|
| 7. |
9804278
|
[4] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 8. |
86512446
|
[4] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 9. |
308761
|
[6] |
CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 10. |
9804277
|
[6] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 11. |
84488987
|
[1] |
ROLLER
|
NH
|
| 12. |
47505113
|
[2] |
BEARING HOUSING
|
PLO
|
