凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (88.100.60[07]) - DIA KIT, DUAL CASTERING WHEEL Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
522 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47459845
|
[1] |
DIA KIT, HARVESTER
|
NH
Dual Castering Wheel, Incl 2 - 26
|
| 2. |
47583684
|
[1] |
INSTRUCTION
|
NH
|
| 3. |
370004
|
[2] |
SNAP RING,M35 x 1.5mm Thk, External
|
NH
Superseded by part number: 11068376
|
| 4. |
87055177
|
[2] |
WHEEL ASSY.
|
PA
Superseded by part number: 87055161, 86611311, 279538, 200734, 136376, 132710, 132709
|
| 5. |
84337334
|
[2] |
CHANNEL
|
PLO
|
| 6. |
84220857
|
[2] |
SPACER,12.7mm ID x 25.4mm OD x 70.5mm L
|
NH
|
| 7. |
9511052
|
[4] |
WASHER,13.5mm ID x 44mm OD x 4mm Thk
|
NH
|
| 8. |
47529253
|
[4] |
WASHER,35.5mm ID x 53mm OD x 2mm Thk
|
PLO
|
| 9. |
374887
|
[2] |
BOLT,Hex, M12 x 1.75 x 100mm, Cl 8.8
|
NH
|
| 10. |
100038
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 11. |
84562237
|
[2] |
ARM
|
NH
|
| 12. |
84567928
|
[1] |
FORK
|
NH
RH
|
| 13. |
87414
|
[2] |
LUBE NIPPLE,1/4" - 28
|
NH
|
| 14. |
87400
|
[2] |
COTTER PIN,3/16" x 2"
|
WIN
|
| 15. |
270184
|
[2] |
LINCH PIN,6.35mm OD
|
NH
|
| 16. |
47431237
|
[2] |
WIRE ROPE
|
NH
|
| 17. |
87056822
|
[2] |
PIN
|
PA
|
| 18. |
84567999
|
[1] |
FORK
|
NH
LH
|
| 19. |
84479182
|
[2] |
PIN,35mm OD x 207mm L
|
PLO
|
| 21. |
9509260
|
[2] |
LOCK BOLT,Hex, M12 x 40mm, Cl 8.8
|
ZED
|
| 22. |
26130
|
[2] |
WASHER,26mm ID x 35mm OD x 1.7mm Thk
|
NH
|
| 23. |
603373
|
[2] |
JAM NUT,Slotted, 1" - 14, Gr 2
|
NH
Superseded by part number: 143183
|
| 24. |
87398
|
[2] |
COTTER PIN,3/16" OD x 1-1/4" OAL
|
NH
|
| 25. |
14408
|
[2] |
WASHER,0.56" ID x 1.25" OD x 0.13" Thk
|
A
Superseded by part number: 425275A1, 425275A1, NLS
|
| 26. |
84012277
|
[2] |
KEY RING
|
ZED
|
