现代零件查询R200W-7 AIRCON & HEATER MOUNTING(#2013-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
797 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
11Q6-90040
|
[1] |
COMPRESSOR ASSY
|
|
| 2. |
11N6-90060
|
[1] |
DRIER-RECEIVER
|
|
| 3. |
11N6-91110
|
[1] |
DIS HOSE ASSY
|
|
| 4. |
11N6-93020
|
[1] |
HOSE(A)-LIQUID
|
|
| 4-1. |
A305000209-2
|
[2] |
O-RING
|
|
| 5. |
11N6-90110
|
[1] |
PULLEY-IDLE
|
|
| 5-1. |
A4760-508-00-2
|
[1] |
BRACKET-PULLEY
|
|
| 5-2. |
A4700-511-01-2
|
[1] |
PULLEY-IDLE
|
|
| 5-3. |
A8900-518-03-3
|
[1] |
BOLT-TENSION
|
|
| 6. |
11N6-91130
|
[1] |
V-BELT
|
|
| 6. |
11N6-90250
|
[1] |
V-BELT
|
|
| 8. |
11L7-90150
|
[1] |
VALVE-HEATER
|
|
| 9. |
14L1-01350
|
[1] |
VALVE-HEATER
|
|
| 9. |
11Q6-90080
|
[1] |
CONNECTOR-HEATER
|
|
| 12. |
S109-080856
|
[3] |
BOLT-SOCKET
|
|
| 13. |
S403-08100B
|
[4] |
WASHER-PLAIN
|
|
| 14. |
S411-080006
|
[4] |
WASHER-SPRING
|
|
| 15. |
S035-061526
|
[2] |
BOLT-W/WASHER
|
|
| 16. |
S205-06100B
|
[2] |
NUT-HEX
|
|
| 17. |
S411-060006
|
[2] |
WASHER-SPRING
|
|
| 18. |
S403-06100B
|
[2] |
WASHER-PLAIN
|
|
| 19. |
S037-102026
|
[3] |
BOLT-W/WASHER
|
|
| 22. |
S593-000902
|
[2] |
CLIP-HARNESS
|
|
| 23. |
S035-081526
|
[1] |
BOLT-W/WASHER
|
|
| 25. |
S403-10200B
|
[4] |
WASHER-PLAIN
|
|
| 26. |
S017-100156
|
[4] |
BOLT-HEX
|
|
| 27. |
S543-400002
|
[2] |
CLAMP-TUBE
|
|
| 28. |
S572-220006
|
[2] |
CLAMP-HOSE,WIRE TYPE
|
|
| 30. |
11N6-90120
|
[1] |
BRACKET-R/DRIER
|
|
| 31. |
S038-103556
|
[1] |
BOLT-W/WASHER
|
|
