纽荷兰零件查询(D125C LT) - CRAWLER DOZER - TIER 4A (10/13-) (48.130.AJ[04]) - FINAL DRIVE New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
335 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | A136128 | [2] | BEARING CUP | IH Superseded by part number: 86577049 |
| 2. | A136127 | [2] | ROLLER BEARING,2.5591" ID x 0.9055" | IH Superseded by part number: 86577049 |
| 3. | 47504510 | [1] | PINION | BUR |
| 4. | 84322474 | [1] | SHIM | BHB |
| 5. | 47506895 | [1] | SHIM | BUR |
| 6. | 84304614 | [1] | FINAL DRIVE HOUSING | BHB |
| 7. | 345335A2 | [7] | PLATE | CAS |
| 8. | 84163978 | [6] | DISC | BRR |
| 9. | 87577298 | [1] | PISTON | BUR |
| 10. | 84296769 | [1] | HOUSING | BUR |
| 11. | 1997880C1 | [4] | SPRING,70.15mm ID x 155mm OD x 3.5mm Thk | IH |
| 12. | 87577303 | [1] | SLEEVE | BUR |
| 13. | 863-10025 | [4] | HEX SOC SCREW,M10 x 25mm, Cl 12.9 | CAS Superseded by part number: 86625209 |
| 14. | 47504331 | [1] | PLATE | BUR |
| 15. | 87452185 | [1] | HUB | BUR |
| 16. | 385236A2 | [1] | SEALING RING | RAC |
| 17. | 385237A2 | [1] | SEALING RING,3.48mm Thk x 156.59mm ID, 70 Duro | RAC |
| 18. | 87591920 | [1] | O-RING,0.139" Thk x 6.48" ID, -260, Cl 7, 75 Duro | BUR |
| 19. | 87591919 | [1] | O-RING,0.139" Thk x 5.984" ID, -258, Cl 7, 75 Duro | BUR |
| 20. | 101-11250 | [2] | SNAP RING,#250, 2.356, Ext | CAS Superseded by part number: 87016255 |
| 21. | 906037R1 | [4] | HEX SOC SCREW,FLAT, M10 x 30mm, Cl 10.9 | CAS |
| 22. | 868-20050 | [4] | 12 PT SCREW,M20 x 50mm, Cl 12.9 | KOB |
| 23. | 87567817 | [1] | SEAL,28mm ID x 40mm OD x 7mm Thk | BUR |
| 24. | 201-101 | [1] | HYD CONNECTOR,11/16"-16 ORFS x 9/16"-18 ORB | CAS Superseded by part number: 9993143 |
| 25. | 9832308 | [1] | BLEEDER | ZED |
| 26. | 87520606 | [2] | PLUG | BRR |
| 27. | 139311A1 | [2] | | RIVET |
| 28. | 87495306 | [2] | PIN,5mm OD x 10mm L | BRR |
