| 1. |
84134472
|
[1] |
DIA KIT, HARVESTER
|
NH
Chain Oiler, Incl 2 - 40 Superseded by part number: 84401609
|
| 2. |
84394647
|
[1] |
INSTRUCTION
|
NH
|
| 3. |
216773
|
[1] |
90 ELBOW,90 Degree, 7/16"-20, 37 Degree x 7/16"-20, O-Ring
|
WIN
|
| 4. |
84414248
|
[1] |
HYDRAULIC HOSE,6.35mm ID x 1625mm L, SAE 100R17
|
PLO
|
| 5. |
9848970
|
[51'] |
PLASTIC-RUBBER TUBE,3.96mm OD x 10973mm L
|
PA
|
| 6. |
86566989
|
[15] |
CABLE TIE,208mm L
|
ZED
|
| 7. |
9804278
|
[2] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 8. |
9804261
|
[2] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 9. |
87667
|
[2] |
SELF-TAP SCREW,Hex Hd, 1/4" x 1/2"
|
GI
|
| 10. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 11. |
9635082
|
[2] |
NUT,5/16" - 18, Gr 5
|
NH
|
| 12. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 13. |
353308
|
[4] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| 14. |
80701
|
[4] |
WASHER,0.31" ID x 0.73" OD x 0.07" Thk
|
NH
|
| 15. |
9804256
|
[4] |
BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8
|
NH
|
| 16. |
326082
|
[2] |
CLAMP,18mm - 25mm
|
ZED
|
| 17. |
86553253
|
[1'] |
HOSE
|
NH
Gates Industrial 3222-0125
|
| 18. |
84292754
|
[3] |
CLIP,Cable Tie W/ Fir Tree, 5mm OD x 203mm OAL
|
NH
|
| 19. |
87040807
|
[1] |
PUMP
|
PA
Oiler
|
| 20. |
86977434
|
[1] |
U-BOLT,5/16" - 20 x 1.94" W x 2.50" L
|
PA
|
| 21. |
9822520
|
[1] |
RESERVOIR, HYDRAULIC
|
NH
2 Quart Capacity
|
| 22. |
9822519
|
[8] |
COMMUTATOR BRUSH
|
NH
|
| 23. |
84476975
|
[1] |
BRUSH HOLDER
|
PLO
|
| 24. |
84476973
|
[1] |
ANGLE
|
PLO
|
| 25. |
47858603
|
[1] |
ANGLE
|
NH
|
| 26. |
47858604
|
[1] |
ANGLE
|
NH
|
| 27. |
84408829
|
[1] |
BRACKET
|
PLO
|
| 28. |
84408830
|
[1] |
SUPPORT
|
PLO
|
| 29. |
47476825
|
[1] |
ANGLE
|
NH
|
| 30. |
9804276
|
[2] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 31. |
86539484
|
[2] |
PIPE PLUG,Sq Hd, 1/8"-27, NTPF
|
NH
|
| 32. |
47478173
|
[1] |
BRACKET
|
NH
|
| 33. |
86050272
|
[2] |
BOLT,M6 x 1 x 18.6mm OAL, Cl 8.8, Full Thd
|
NH
|
| 34. |
47486748
|
[1] |
ANGLE
|
NH
|
| 35. |
86521981
|
[2] |
REDUCER,5/32" Hose Barb x 5/32" Hose Barb
|
PA
|
| 36. |
9804258
|
[1] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 37. |
87656363
|
[1] |
HYD CONNECTOR,3/4" - 16 x 3/4" - 16 x 7/16" - 20 x 2-1/8" L
|
NH
|
| 38. |
47503448
|
[1] |
ANGLE
|
NH
|
| 39. |
47503454
|
[1] |
BRACKET
|
NH
|
| 40. |
47503000
|
[1] |
BRACKET
|
NH
|
