| 1. |
47565143
|
[1] |
DOOR
|
NH
Front, Incl 17, Serial Range: -YFN188618 Superseded by part number: 47973214
|
| 1. |
47973214
|
[1] |
DOOR
|
NH
Front, Incl 17, Start Serial: YFN188619
|
| 2. |
84133414
|
[2] |
ROD
|
NH
|
| 3. |
47483296
|
[2] |
BRACKET
|
NH
|
| 4. |
86639602
|
[2] |
GAS STRUT
|
NH
|
| 5. |
84384384
|
[2] |
DOOR SILL MOULDING
|
PLO
|
| 6. |
86628347
|
[4] |
STUD,M8 x 36.5mm OAL, 10mm OD Ball
|
NH
|
| 7. |
86507486
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 8. |
9804278
|
[2] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 9. |
86619801
|
[12] |
FLANGE NUT,M8 x 1.25, Cl 8
|
PA
Superseded by part number: 87681210
|
| 10. |
9804277
|
[4] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 11. |
128104
|
[2] |
BUMPER
|
NH
|
| 12. |
86633356
|
[2] |
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
|
ZED
|
| 13. |
1570477
|
[1] |
BOLT,Hex, M12 x 1.75 x 110mm, Cl 8.8, Full Thd
|
BER
Superseded by part number: 614-12110
|
| 14. |
86511324
|
[4] |
WASHER,13mm ID x 24mm OD x 2.5mm Thk
|
NH
Superseded by part number: 87364
|
| 15. |
9706685
|
[3] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 16. |
9671714
|
[8] |
FLANGE BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 17. |
47404857
|
[1] |
DANGER DECAL
|
NH
Superseded by part number: 86642359, 47361282, 84004731, 47361328, 47361307
|
