凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (90.105.BH[02]) - DOOR, RH Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
632 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47514339
|
[1] |
DOOR
|
NH
LH, Incl 11, 12
|
| 2. |
47557070
|
[1] |
SHIELD
|
NH
|
| 3. |
47554952
|
[1] |
BRACKET
|
NH
|
| 4. |
47419812
|
[1] |
BRACKET
|
PLO
|
| 5. |
84542874
|
[1] |
HANDLE
|
NH
|
| 6. |
47554123
|
[1] |
PLATE
|
NH
|
| 7. |
280250
|
[1] |
COTTER PIN,3/32" OD x 3/4" L
|
NH
|
| 8. |
9804277
|
[1] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 9. |
9804258
|
[16] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 10. |
86588501
|
[1] |
WASHER,11mm ID x 20mm OD x 2.5mm Thk
|
GI
|
| 11. |
47361329
|
[1] |
DANGER DECAL
|
NH
|
| 12. |
84004734
|
[1] |
WARNING DECAL
|
ZED
|
