凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (90.119.AB[01]) - VAR - 722000 - ROTOR SHIELD, LH Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
288 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47561748
|
[1] |
SHIELD
|
NH
Incl 9, 10
|
| 2. |
47448361
|
[1] |
SHIELD
|
NH
|
| 3. |
84572953
|
[2] |
SHAFT
|
PLO
|
| 4. |
47505101
|
[1] |
SHAFT
|
NH
|
| 5. |
86610200
|
[4] |
THREADED INSERT,M8 x 1.25
|
NH
|
| 6. |
9804258
|
[7] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 7. |
86507486
|
[3] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 8. |
86050286
|
[2] |
FLANGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 9. |
47361323
|
[1] |
DANGER DECAL
|
NH
|
| 10. |
47361283
|
[1] |
DANGER DECAL
|
NH
|
