纽荷兰零件查询(D125C LT) - CRAWLER DOZER - TIER 4A (10/13-) (55.518.AP[01]) - WINDSHIELD WASHER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
721 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 425-106 | [2] | NUT,3/8"-16, Cl 5 | CASHex Superseded by part number: 9628503 |
| 2. | 80680 | [2] | LOCK WASHER,3/8 0.381 CST ZND | NH |
| 3. | 5155855 | [1] | BRACKET | BASWiper Tank Fixing |
| 4. | 84293452 | [1] | WINDSHIELD WASH RESERVOIR | DUB |
| 5. | 86977726 | [4] | BOLT,Hex, M6 x 12mm, Cl 8.8 | ZED |
| 6. | 87427778 | [1] | FITTING | CASTee-3/16 650-850K |
| 7. | 87655041 | [4] | SPECIAL WASHER,6.85mm ID x 13.5mm OD x 2mm Thk | BURM6 x 6.85 x 12.75 x 1.8 Hts Boron |
| 8. | 284154A1 | [2] | NOZZLE,3/8" - 16 | CASWasher |
| 9. | 305578A1 | [6] | CLAMP,7.65mm - 8.76mm | CASHose, Ctb 7.6-8.8mm Um5005 |
| 10. | L11541 | [13] | CABLE TIE,203.2mm L, Nylon | CASTie, 7/8 Superseded by part number: 87000312 |
| 11. | 1968141C1 | [1] | HOSE | IH50' Cut to Lenght |
| 12. | 47426336 | [1] | TAPE | BUR25M Cut to Length |
