| 1-50. | VAME150109 | [1] | AIR COMPRESSOR | KOBASSY, 1 CYL, M0 ONLY Superseded by part number: 132554A1 |
| . . | VAME150115 | [1] | AIR COMPRES ASSY, 2CYL, M5 ONLY | AIR COMPRES ASSY, 2CYL, M5 ONLY |
| 1. | VAME057119 | [1] | CRANK CASE ASSY, M0 ONLY, MITSUBISHI PART NO. (ME713000) | CRANK CASE ASSY, M0 ONLY, MITSUBISHI PART NO. (ME713000) |
| . . | VAME057129 | [1] | M5 ONLY | |
| 2. | VAMF472586 | [2] | PIN, SPG 6X14, M5 ONLY | |
| 4-5. | VAME713230 | [1] | HOLDER | KOBM0 ONLY |
| . . | VAME713233 | [1] | M5 ONLY | |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONHOLDER, BRG |
| 5. | VA3097520600 | [1] | PISTON RING SET | KOBOILSEAL, MITSUBISHI PART NO. (ME713004) |
| 8-13. | VA3097501040 | [1] | CONN. ROD SHELL | KOBCONNECTING ROD ASSY, M0 ONLY |
| . . | VA3097503040 | [2] | M5 ONLY | |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONROD, CONNECTING, M0 ONLY |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, CONN-ROD, M0 ONLY |
| 10. | VA3097520900 | [2] | BEARING C0NNECTING BEARING, M0 ONLY, AVAILABLE IN SET WITH PAIR | BEARING C0NNECTING BEARING, M0 ONLY, AVAILABLE IN SET WITH PAIR |
| 11. | VAME713093 | [2] | BOLT | KOBM0 ONLY |
| 12. | VA3097525100 | [2] | NUT NUT, CONN-ROD, M0 ONLY | NUT NUT, CONN-ROD, M0 ONLY |
| 13. | VA3097521200 | [2] | LOCK WASHER WASHER, LOCK, M0 ONLY | LOCK WASHER WASHER, LOCK, M0 ONLY |
| 14-31. | VAME713206 | [1] | CYLINDER HEAD | KOBM0 ONLY Superseded by part number: 132569A1 |
| . . | VA3097503060 | [1] | M5 ONLY | |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONHEAD, CYL |
| 15-20. | VA3097502060 | [1] | STD INLET VALVE | KOBSTD ENGINE INLET VALVE DELIVERY VALVE KIT, M0 ONLY Superseded by part number: 132608A1 |
| . . | VA3097503090 | [1] | M5 ONLY | |
| 15. | VA3097522500 | [1] | SPRING,DELIVERLY SPRING, DELIVERY/V, M0 ONLY | SPRING,DELIVERLY SPRING, DELIVERY/V, M0 ONLY |
| 16. | VA3097522600 | [1] | VALVE,DELIVERLY VALVE, DELIVERY, M0 ONLY | VALVE,DELIVERLY VALVE, DELIVERY, M0 ONLY |
| 17. | VA3097522700 | [1] | DELIVERY/V, M0 ONLY | |
| . . | VA3097517800 | [2] | M5 ONLY | |
| 18. | VA3097522800 | [2] | GASKET | KOBDELIVERY/V, M0 ONLY Superseded by part number: 132567A1 |
| . . | VA3097518100 | [2] | O-RING, M5 ONLY | |
| 19. | VA3097522900 | [1] | O-RING O-RING, M0 ONLY | O-RING O-RING, M0 ONLY |
| . . | VA3097517900 | [2] | M5 ONLY | |
| 20. | VAME713224 | [1] | HOLDER, INJECTOR NOZ | KOBDELIVERY VALVE, M0 ONLY Superseded by part number: 132571A1 |
| . . | VA3097504010 | [2] | M5 ONLY | |
| 20A. | VAME713209 | [1] | VALVE DELIVERY SET, M0 ONLY, FOR SERVICE ONLY | VALVE DELIVERY SET, M0 ONLY, FOR SERVICE ONLY |
| 21-25. | VA3097502070 | [1] | STD INLET VALVE | KOBSTD ENGINE INLET VALVE SUCTION VALVE KIT, M0 ONLY Superseded by part number: 132611A1 |
| . . | VA3097503080 | [1] | M5 ONLY | |
| 21. | VA3097523100 | [1] | SUCTION, M0 ONLY | |
| . . | VA3097516900 | [2] | M5 ONLY | |
| 22. | VA3097523200 | [1] | SPRING SPRING, SUCTION, M0 ONLY | SPRING SPRING, SUCTION, M0 ONLY |
| 23. | VA3097523300 | [1] | VALVE VALVE, SUCTION, M0 ONLY | VALVE VALVE, SUCTION, M0 ONLY |
| . . | VA3097517100 | [2] | M5 ONLY | |
| 24. | VA3097523400 | [1] | SUCTION, M0 ONLY | |
| . . | VA3097517200 | [2] | M5 ONLY | |
| 25. | VA3097523500 | [1] | GASKET,SUCTION GASKET, SUCTION, M0 ONLY | GASKET,SUCTION GASKET, SUCTION, M0 ONLY |
| 26. | VA3097523600 | [1] | PLUG PT3/4, M0 ONLY | |
| . . | VA3097523600 | [1] | M5 ONLY | |
| 29-31. | VA3097501070 | [1] | HYDRAULIC VALVE | KOBUNLOADER VALVE ASSY, M0 ONLY Superseded by part number: VAME713027 |
| . . | VA3097503070 | [2] | M5 ONLY | |
| 29. | NSS | [1] | NOT SOLD SEPARAT | CONVALVE, UNLOADER, M0 ONLY |
| 30. | VA3097524200 | [1] | SPRING,UNLOADER SPRING, UNLOADER, M0 ONLY | SPRING,UNLOADER SPRING, UNLOADER, M0 ONLY |
| . . | VA3097517400 | [2] | M5 ONLY | |
| 31. | VA3097524300 | [1] | RING, SNAP RING, SNAP, M0 ONLY | RING, SNAP RING, SNAP, M0 ONLY |
| . . | VA3097517600 | [2] | CLIP M5 ONLY | CLIP M5 ONLY |
| 32. | VAME713281 | [1] | CRANK SHAFT M0 ONLY | CRANK SHAFT M0 ONLY |
| . . | VAME713283 | [1] | M5 ONLY | |
| 33. | VA3097520400 | [1] | O-RING | KOBO-RING, M0 ONLY, MITSUBISHI PARTS NO. (ME713002) Superseded by part number: 132630A1 |
| . . | VA3097515500 | [1] | M5 ONLY | |
| 34. | VAMF101256 | [4] | BOLT 8X22, M0 ONLY | |
| . . | VA334013024 | [4] | WASHER, SPG 8, M0 ONLY, MITSUBISHI PARTS NO. (MF450405) | |
| 34A. | VA3097515700 | [2] | STUD, M5 ONLY | |
| . . | VAMF430005 | [2] | NUT | KOBNUT 8, M5 ONLY Superseded by part number: VAF230008000 |
| 35. | VAME713114 | [1] | PISTON | KOBPISTON, M0 ONLY Superseded by part number: 132597A1 |
| . . | VAME713110 | [2] | MANIFOLD M5 ONLY | MANIFOLD M5 ONLY |
| 36. | VAME713327 | [1] | PISTON RING | KOBM0 ONLY Superseded by part number: 132598A1 |
| . . | VAME713328 | [1] | PISTON RING SET M5 ONLY | PISTON RING SET M5 ONLY |
| 39. | VA3097521700 | [1] | PIN | KOBPIN, PISTON, M0 ONLY Superseded by part number: 132581A1 |
| . . | VA3097516100 | [2] | M5 ONLY | |
| 40. | VA3097521800 | [2] | RING,SNAP RING, SNAP, M0 ONLY | RING,SNAP RING, SNAP, M0 ONLY |
| . . | VA3097516200 | [4] | COLLAR | KOBM5 ONLY Superseded by part number: 3097516200 |
| 41. | VA3097521900 | [1] | O-RING | KOBGASKET, LINER, M0 ONLY Superseded by part number: VAME713329 |
| . . | VA3097516600 | [1] | GASKET | KOBM5 ONLY Superseded by part number: VAME713331 |
| 42. | VA3097522100 | [1] | HYD CONNECTOR | KOBLINER, CYL, M0 ONLY Superseded by part number: 132575A1 |
| . . | VA3097516500 | [1] | LINER, ENGINE CYLIND | KOBM5 ONLY Superseded by part number: VAME713054 |
| 45. | VAMF129648 | [6] | BOLT BOLT 10X30, M5 ONLY | BOLT BOLT 10X30, M5 ONLY |
| . . | VAMF450406 | [6] | WASHER | KOBWASHER, SPG 10, M5 ONLY |
| 46. | VAME713208 | [4] | STUD, M0 ONLY | |
| . . | VA634831018 | [4] | NUT 10, M0 ONLY | |
| . . | VA3097518200 | [5] | BOLT 10X65, M5 ONLY | |
| 46A. | VAMF130568 | [1] | BOLT 10X30, M5 ONLY | |
| 47. | VA3097524500 | [1] | O-RING | KOBGASKET, HEAD, M0 ONLY Superseded by part number: 132565A1 |
| . . | VA3097516700 | [1] | M0 ONLY | |
| 48. | VA3097524600 | [1] | COLLAR CLAMP | KOBCOLLAR, MITSUBISHI PART NO. (ME713030) Superseded by part number: 132559A1 |
| 49. | VAME713031 | [1] | BRACKET, M0 ONLY | |
| 50. | VAME713196 | [1] | UNIVERSAL JOINT | KOBJOINT, M0 ONLY, MITSUBISHI PART NO. (MH038303) |
| . . | VAME713196 | [1] | UNIVERSAL JOINT | KOBJOINT, M5 ONLY, MITSUBISHI PART NO. (MH030303) |
| 60. | VAME713210 | [1] | SEAL KIT | KOBSEAL KIT, FOR SERVICE ONLY |
