凯斯零件查询(RB455A) - UTILITY CASE IH ROUND BALER (1/10-12/14) (39.100.01) - TAILGATE, LH Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
196 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84289489
|
[1] |
TAILGATE
|
NH
Includes: Ref. 3
|
| 2. |
47853261
|
[1] |
HOOK
|
NH
LH
|
| 3. |
86631519
|
[1] |
DANGER DECAL
|
NH
|
| 4. |
87399
|
[4] |
COTTER PIN,1/2 x 3 Bolt
|
GI
|
| 5. |
26306
|
[1] |
DRIVE BUSHING,25.47mm ID x 31.82mm OD x 31.8mm L
|
NH
|
| 6. |
9600196
|
[1] |
SPACER,32.23mm ID x 39.7mm OD x 29.98mm L
|
NH
Superseded by part number: 86636674
|
| 7. |
86977433
|
[1] |
SPACER,13.11mm ID x 19.05mm OD x 12.7mm Thk
|
PA
Superseded by part number: 86622618
|
| 8. |
166065
|
[1] |
PIN,25.4mm OD x 66.5mm L
|
NH
|
| 9. |
605846
|
[1] |
SPRING,Extension, 25.4mm OD x 243.8mm L
|
NH
Superseded by part number: 87054556
|
| 10. |
144403
|
[1] |
EYEBOLT
|
NH
|
| 11. |
9804268
|
[1] |
BOLT,Hex, M12 x 40mm, Cl 8.8, Full Thd
|
NH
|
| 12. |
64972
|
[2] |
WASHER,32.54mm ID x 50.8mm OD x 3.43mm Thk
|
NH
|
| 13. |
47919326
|
[1] |
PIN
|
NH
|
| 14. |
164995
|
[3] |
WASHER,32.5mm ID x 42.9mm OD x 4.38mm Thk
|
NH
|
| 15. |
87362
|
[1] |
WASHER,5/16" SAE
|
NH
Superseded by part number: 83918746
|
| 16. |
9635082
|
[1] |
NUT,5/16" - 18, Gr 5
|
NH
|
| 17. |
80700
|
[1] |
WASHER,0.56" ID x 1.38" OD x 0.11" Thk
|
NH
|
| 18. |
84485261
|
[1] |
LATCH
|
NH
LH, Adjustable
|
| 19. |
9804278
|
[2] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 20. |
374892
|
[2] |
CARRIAGE BOLT,M10 x 1.5 x 40mm, Cl 8.8
|
NH
|
